Antena Parabolica Offset Profesional AMP 1.5 m Acero electrocincado
Antena Parabolica Offset Profesional AMP 1.5 m Acero electrocincado
€556.60
Tax included
Reference
AMP86
Brand
AMP
This product is not sent to some countries or areas, if the cart does not have available carriers, you can contact us here
AMP Professional Offset Parabolic Antenna 1.5 m Electrozinc plated steel
The most advanced CAD design of the parabolic antennas guarantees its optimum performance.
Made of electrogalvanized steel and with polyester coating that prevents deterioration due to aging
Specifications
| Diameters | 150x165mm |
| Angle Offset | 24.62º |
| Band C gain at 4.0 GHz | 34.72dB |
| KU band gain at 12.5 GHz | 43.80 dB |
| Focal distance | 90.0 cm |
| Elevation Angle | 17º - 90º |
| Azimuth | 0º - 360º |
| Efficiency | 70% min |
| Focus / Diameter Ratio | 0.6 |
| Painting | Polyester |
| Colour | Gray |
| Mounting type | G / P / W |
| Material | Electrogalvanized steel |
| Fixing bracket diameter | 76mm Ø |
| Temp. of work | -40ºC / + 60ºC |
| RH | 0-100% |
| Net weight | 35.3 Kg |
| Wind Resistance (Operational) | 150Km / h |
| Wind Resistance (Mechanical) | 200 km / h |
