LNB Inverto Classic Single C-Band Flange
Specifically designed for the DTH markets, this LNB provides optimized reception capabilities. It enables the reception of signals from one satellite and its distribution to a single tuner Set-top box. It is ready for High Definition transmissions and provides excellent Noise Figure performance.
€22.88
Tax included
Reference
inverto-3113
Brand
Inverto
LNB Inverto Classic Single C-Band Flange
€22.88
Specifically designed for the DTH markets, this LNB provides optimized reception capabilities. It enables the reception of signals from one satellite and its distribution to a single tuner Set-top box. It is ready for High Definition transmissions and provides excellent Noise Figure performance. Designed to meet strict specifications and manufactured to the highest industry quality standards , this LNB is an ideal solution for the satellite broadcast reception across Europe.
Main Features
- Low Phase-Noise, DVB-S2 (HDTV) compliant
- Low Noise-Figure (Max. 13° K)
- Low Power Consumption
- High Frequency Stability
Specs
| Inverto | IDLB-SINFOC00-OOPRO-OPP |
|---|---|
| Input Frequency Range (Vertical & Horizontal) | 3.4 ~ 4.2 GHz |
| Output Frequency Range (Vertical & Horizontal Switchable) | 950 ~ 1750 MHz |
| LO Frequency | 5.15 GHz |
| Noise Figure | 13 °K Max. |
| LO Initial Accuracy | +/- 1.0 MHz Max. |
| LO Temperature Drift | +/- 2.0 MHz Max. |
| Phase Noise (@ 10 kHz) | - 90 dBc/Hz Max. |
| Conversion Gain | 60 dB Min. |
| Gain Ripple (Over 26MHz Bandwidth) | +/- 0.75 dB |
| Gain Variation (Over Full Band) | +/- 4 dB Max. |
| Image Rejection | 40 dB Min. |
| 1 dB Compression Point (@ Output) | 0.0 dBm Min. |
| Cross Polarization Isolation | 22 dB Min. |
| Output VSWR | 2.5 : 1 |
| In-Band Spurious | - 60 dBm Max. |
| Current Consumption | 190 mA Max. @ 11 ~ 20 V |
| Operating Temperature | - 25 °C ~ + 60 °C |
| Output Impedance | 75 Ω |
| Output Connector | F-Type (Female) |
| Weight | 175 g |
