SELECT * FROM ps_od_oosbutton_manufacturer WHERE id_manufacturer = 7SELECT * FROM ps_od_oosbutton JOIN ps_od_oosbutton_lang USING (id_product) WHERE id_product = 13530 AND id_lang = 1 Promax IC-016B Low voltage installation tester
search

Promax IC-016B Low voltage installation tester

It allows the measurement of the contact voltage without activating the differential protections, as well as other special measures such as phase sequence, voltage drop and surface insulation.

€3,303.30
Tax included
Reference promax-ic-016b
Brand Promax
Quantity
Available in 24/48h

Free shipping

Promax IC-016B Low voltage installation tester

€3,303.30

It allows the measurement of the contact voltage without activating the differential protections, as well as other special measures such as phase sequence, voltage drop and surface insulation.

The universal low voltage installations tester model IC-016B allows the measurement of the contact voltage without activating the differential protections, as well as other special measures such as phase sequence, voltage drop and surface insulation.

It is the ideal equipment for inspection and regulatory control entities, authorized installers, maintenance companies of public places, inspectors of official services, occupational safety and health cabinets, employer mutual funds, etc.

The IC-016B has a user interface in Spanish and memory capacity for 50,000 objects with USB port for data transmission to PC and data processing software.

Contact current measurement without triggering differential protections

  • Measurement of voltage, frequency and direction of the rotating field
  • Loop / network impedance measurement
  • RCD protection circuit measurement
  • Resistance and grounding voltage
  • Local insulation resistance / insulation measurement
  • Equipotential resistance
  • Leakage current measurement with pincer transformer
  • Counter Start

Specifications

DIFFERENTIAL PROTECTION MEASURES
  • Contact voltage measurement (UB) without triggering the differential
  • Shooting time
  • IF trip current measurement
  • Selective protection
  • Normal differentials, portable residual current devices, type G / R
  • Neutral-Earth Investment Test
  • ZL-PE / ZL-N loop impedance measurement
  • Grounding Resistance RE
  • Selective resistance to grounding RE
  • RLO equipotential protection
  • RISO insulation resistance
  • Line-neutral voltage, line-to-ground voltage, line frequency
SPECIAL MEASURES
  • Leakage current (with pincers) IL, IAMP
  • Sequence of phases
  • Earth resistance RE (ISO)
  • Voltage drop (ΔU)
  • ZST local isolation
  • Counter start (kWh test)
FEATURES
  • Selectable user interface language
  • Memory (database for up to 50,000 objects)
  • Auto Test Sequence Function
  • RS-232 interface for RFIB scanner / barcodes
  • USB port for data transfer
  • ETC software for PC
  • Measurement category: CAT III 600 V / CAT IV 300 V
  • DAkkS calibration certificate

Download

data sheet
