Data sheet

Weight

773 g

Power

100-240 VAC, 50/60 Hz
AC 110~250 V, 50/60 Hz
DC 12 V / 850 mA max. / estándarIEEE802.3af PoE

Technology

PIR
Volumetric PIR with photo camera

Detection range

12 m / H: 88.5º / V: 80º / Installation 2.4 m

Frequency

868 MHz Jeweller
868 MHz Jeweller and Wings (sending images)

Pet immunity

≤ 20 kg, ≤ 50 cm

Masking

No

Sensitivity

Adjustable. 3 levels (low, medium and high)

LEDs indication

Alarm, tamper, signal

Battery

1 battery CR123A 3.0 V (approximate life time 7 years)
1 battery CR2032 3.0 V (approximate life time 5 years)
2 CR123A3.0 v-batteries (life up to 4 years)

Temp. operation

+5º C ~ 40º C
-20º C ~ 50º C
-30º C ~ +50º C
0º C ~ 40º C
0º C ~ 50º C

Degree of protection

IP66, anti-vandalic IK09

Security grade

Grade 2

Transmission distance

≤ 1300 m in open space
≤ 1700 m in open space

Housing material

ABS plastic

Internal security

Tamper-resistant opening

Dimensions

65 (H) x 37 (W) x 10 (D) mm
161.9 (H) x 74.1 (W) x 53.2 (D) mm
163 (H) x 163 (W) x 36 (D) mm

PIR lens

24 zones and 6 planes

Backup battery

Duration up to 16 hours

Internal siren

No

Inputs

Exit button, feedback, door sensor, tamper

Material

Zinc alloy

Dimensions / Weight

52 (H) x 385 (W) x 315 (D) mm / 3.0 Kg (without HDD)

Range

HiWatch Series

RF frequency

868 MHz. Protocol via Jeweller wireless technology

Communication

2 x USB 2.0 / 1 x RJ45 10/100/1000 (Ethernet)
Ethernet / Dual SIM 2G (GPRS)

Maximum devices

100

Number or users

Up to 50

Functions

Armed, disarmed, partially armed and panic

Compatibility

AJ-HUB2-W/B
Not compatible with ocBridge and uartBridge

Audio

Bidirectional audio with microphone and speaker

Operating system

LINUX OS

Image sensor

2Mpx with WDR

Lens

3.47mm Pinhole

Infrared lighting

IR for night mode

Relay

1 for lock control.

Viewing angle

H: 88º D: 45º (Device rotates between -50º ~+50º manually when installing)

Inputs for IP cameras

LAN port up to 16 channels

IP compatible cameras

HIKVISION, ONVIF

Bidirectional audio

1 input / 1 RCA output

Video compression format

H.265+ / H.265 / H.264+ / H.264

Display resolution

3840x2160, 2560x1440, 1920x1080, 1600x1200, 1280x1024, 1280x720, 1024x768

Total bandwidth

160 Mbps downstream / 160 Mbps upstream

Main Stream recording

8MP/6MP/5MP/4MP/3MP/1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF

Simultaneous multifunction

Pentaplex: Live, Recording, Playback, Backup and Remote Access

Alarms

4 inputs / 1 relay

Recording method

Manual, programmed, motion detection, alarm

External Backup

USB memory / HDD USB / CD-RW USB / DVR-RW USB

Internal memory

2 SATA HDD 3.5\" of up to 6 TB (not included)

Remote access

Web Browser, Smartphone App IVMS 4500 and PC Software IVMS 4200
Web browser, phone app or Safire Control Center-software

Network interface

Ethernet 10/100 BaseT

Video outputs

1 HDMI 4K, 1 VGA

Image resolution

Up to VGA (640 x 480)

Decoding capacity

2CH @ 8 MP (25fps) / 4CH @ 4MP (30fps) / 8CH @ 1080p (30fps)

Infrared light

IR with range up to 5 meters

Events

Motion detection and image captures

Power over Ethernet

16 port PoE Switch IEEE802.3af/at (max. 75 W)

Video integration

Up to 25 IP cameras or video recorder channels

Connection with CRA

Contact ID / SIA

Keypad

Mechanical call button

Dimensions (without bracket)

110 (H) x 65 (W) x 50 (D) mm
135 (H) x 70 (W) x 60 (D) mm

Number of images

Up to 5 images per detection

Sending images

Sending and receiving images in less than a minute
