Data sheet

Weight

292 g
750 g
800 g

Power

1 battery CR2032 of 3 V
48 V DC / 800 mA max
AC 110~250 V, 50/60 Hz
DC 12 V / 3.7W
DC 12 V / 1000 mA max. / IEEE802.3af PoE
DC 12 V / 1000 mA max. / standard PoE (IEEE802.3af)

Technology

Volumetric PIR with photo camera

Detection range

12 m / H: 88.5º / V: 80º / Installation 2.4 m

Frequency

868 MHz
868 MHz Jeweller and Wings (sending images)

Pet immunity

≤ 20 kg, ≤ 50 cm

Masking

No

Sensitivity

Adjustable. 3 levels (low, medium and high)

LEDs indication

Alarm, tamper, signal

Battery

1 battery CR123A 3.0 V (approximate life time 5 years)
1 battery CR123A 3.0 V (approximate life time 7 years)
2 CR123A3.0 v-batteries (life up to 4 years)

Temp. operation

+5º C ~ 40º C
-10º C ~ +55º C
-20º C ~ 50º C
-40º C ~ +53º C
-40º C ~ +60º C
0º C ~ 40º C

Degree of protection

IP65, IK08
Suitable for exterior IP66

Security grade

Grade 2

Transmission distance

≤ 1000 m in open space
≤ 1700 m in open space
≤ 2000 m in open space

Housing material

ABS plastic

Internal security

Tamper-resistant opening

Dimensions

65 (H) x 37 (W) x 10 (D) mm
83.1 (D) x 27.6 (H) x 105 (W) mm
90 mm (D) x 20 (Ø) mm
158.6 (D) x 61 (W) x 58 (H) mm
163 (H) x 163 (W) x 36 (D) mm
182 (H) x 100 (W) x 33 (D) mm
200 (H) x 140 (W) x 15.1 (D) mm

PIR lens

24 zones and 6 planes

Operating temperature

0º C - 40º C

Backup battery

Duration up to 15 hours

Internal siren

No

Inputs

8 Configurable alarm entries
Exit button, feedback, door sensor, tamper

Power supply

Up to 30 W per port (35 W for the complete device)

Material

Metallic
Stainless steel

Range

HiWatch Series

RF frequency

868 MHz. Protocol via Jeweller wireless technology

Communication

Ethernet / Wi-Fi / Dual SIM 4G (LTE)

Maximum devices

200

Number or users

Up to 200

Compatibility

AJ-HUB2-W/B
Not compatible with ocBridge and uartBridge

Video output

1 x BNC switchable HDTVI 2.0 / HDCVI / AHD / CVBS
HD 1080p (1920x1080) at 25 FPS

Audio

Bidirectional audio with microphone and speaker
Two-way audio with microphone and speaker with noise reduction

Operating system

LINUX OS

Memory

Slot MicroSD up to 32GB

Image sensor

1/3\" 2 Megapixel CMOS
High Performance CMOS

Minimum illumination

0 Lux / EXIR IR (30 m)

Basic functions

OSD menu, Day/Night with IR-CUT (ICR)

Configurable OSD functions

DWDR, BLC, HLC, DNR, AWB, AGC, Smart IR

Lens

2.8 mm

Infrared lighting

IR for night mode

Relay

2 for lock control.

Remote access

Mobile app or Safire Control Center-software
Web browser, phone app or Safire Control Center-software

Network interface

Ethernet 10/100 BaseT, WiFi (Only for App connection via P2P)
Ethernet 10/100 BaseT / RS485 / RTSP / WiFi 802.11b/g/n (Only for connection to App through P2P)

PoE features

According to norm IEEE 802.3at PoE+ / IEEE 802.3af PoE

Interface

4 PoE ports RJ45 + 1 Uplink Port

Access control

Door opening with MF card 13.65MHz to 256

Image resolution

Up to VGA (640 x 480)

Port speed

4x 10/100 - 1x 10/100 Mbps

LCD

7\" 1024x600, Capacitive

Operation mode

Tactile Buttons

Video integration

Up to 100 IP cameras or video recorder channels

Connection with CRA

Contact ID / SIA

Keypad

Mechanical button with LED backlit name-tag

Dimensions (without bracket)

135 (H) x 70 (W) x 60 (D) mm

Number of images

Up to 5 images per detection

Sending images

Sending and receiving images in less than a minute
