Amplifier FM/DAB TAS 240 40dB Triax
This module allows the FM and DAB signals to be amplified separately. The gain can be regulated from 0 - 20 dB in each frequency band.
€56.34
€112.68
Save 50%
Tax included
Reference
triax-324848
Brand
Triax
Amplifier FM/DAB TAS 240 40dB Triax
€56.34
€112.68
Save 50%
This module allows the FM and DAB signals to be amplified separately. The gain can be regulated from 0 - 20 dB in each frequency band.
Specifications
| Model | TAS 240 | |
| Code | 324848 | |
| Frequency band | MHz |
FM: 87.5 - 108 DAB: 195 - 223 |
| Gain | dB | 40 |
| Attenuation | dB | 0 - 20 |
| Output level | dBμV |
110 (DIN B - 35dB) |
|
Feeding |
VCD | 12 to 24 |
| Consumption | mA | 150 |
| Connectors | F female | |
| Impedance | Ω | 75 |
| Dimensions | mm. | 225 x 65 x 30 |
Example of chassis mounting
