Televes MicroKom: Launch amplifier T4 RET/MATV G(-||20)/(20||25)dB

Launch amplifiers with active or passive return path designed for multimedia services distribution in small/medium size buildings.

€194.11
Tax included
Reference televes-534211
Brand Televes
Quantity
Available in 24/48h

Free shipping
Televés MicroKom: Launch amplifier T4 RET/MATV G(-||20)/(20||25)dB

Televes MicroKom: Launch amplifier T4 RET/MATV G(-||20)/(20||25)dB

€194.11

Launch amplifiers with active or passive return path designed for multimedia services distribution in small/medium size buildings.

Main Features

  • Adjustments via plug-in jumpers with a very intuitive block diagram as support.
  • Fully configurable return path equipped with attenuator and equalizer.
  • Direct channel with independent attenuator and equalizer adjustment between stages.
  • High output level (121dBμV DIN45004B)
  • Zamak chassis.

Specs

Reference 534211
 Forward path
 Frequency range MHz 85...1006
 Gain dB 25
 Input attenuator dB 0...18 (2dB steps)
 Interstage attenuator dB 0/5
 Input equalizer dB 0...18 (2dB steps)
 Interstage equalizer dB 0/6
 Noise figure dB 6
 Output level dBµV 121 (DIN45004B)
 Return path
 Frequency MHz 5...65
 Gain dB 20/-1
 Input attenuator dB 0...18 (2dB steps)
 Interstage equalizer dB 0/3/6
 Ouput level dBµV 118 (DIN45004B)
 General
 Main voltage Vac/Hz 99 - 253 / 50 - 60
 Power consumption W 5
 Electrostatic discharges protection kV 8 (EN61000-4-2)
 Protection class class II isolation
 Protection index IP 20

Additional information

Product release

Data Sheet
