Main features

• Versatile transmodulation of DVB-T/T2, DVB-S/S2 and DVB-C channels to DVB-T/DVB-C channels.
• The HTL-STC module can receive 2 DVB-T/T2, DVB-S/S2 or DVB-C muxes and combine them on 2 DVB-T or DVB-C output channels.
• One module acts as the “master” to ensure the configuration (remote or local through PC) is carried out at the complete headend level, through the IKUNET bus and not module by module.
• The Wizard installation assistant allows us to carry out a step-by-step headend configuration that is quick and easy.
• It has a Common Interface (EN 50221) for discretional decryption of programmes in accordance with the inserted CAM module.
• It allows a future increase in services to be foreseen in order for the televisions to have them already on their lists, avoiding the need for retuning.
• It allows a video service to be sent with several different languages without taking up more space than that corresponding to an RF channel. The television shows “a programme” for each language, avoiding the need for users to have to choose their “language” on the television remote control.
• It is compatible with the PC application: “IKUSI HEADEND DISCOVERY” This instrument provides installers with a tool that allows them to detect the headend’s modules without having to modify the PC’s network configuration. (This can be downloaded from www.ikusi.tv).
• It allows grids of channels to be created and managed remotely, ensuring that the grid is completely customisable without having to intervene in-situ.
• The two DVB-T/C output channels can be distributed onto any part of the band.
• Total control of the multiswitch. Fitted with DiSEqC

Additional info

Data Sheet

Installation Guide

Interface web guide HTL-STC
