Data sheet

Power

AC 100V~240V ≤15W (Without HDD)

Dimensions / Weight

66.8 (H) x 440 (W) x 320 (D) mm / 4.1 Kg

Communication

1 x USB 3.0, 2 x USB 2.0 / 2 x RJ45 (Ethernet)

Inputs for IP cameras

LAN port up to 16 channels

IP compatible cameras

MILESIGHT (native protocol), ONVIF

Bidirectional audio

1 input / 1 RCA output / via HDMI

Video compression format

H.265+ / H.265 / H.264+ / H.264

Display resolution

3840x2160, 3840x2160, 1920x1080, 1920x1080, 1280x1024, 1280x720, 1024x768

Total bandwidth

160 Mbps downstream / 160 Mbps upstream

Main Stream recording

4x 8MP, 5x 6MP, 6x 5MP, 8x 4MP, 10x 3MP, 16x 1080p, 16x 720p [%VAR%] [%VAR%]

Simultaneous multifunction

Pentaplex: Live, Recording, Playback, Backup and Remote Access

Alarms

16 IN / 4 OUT

Recording method

Manual, programmed, motion detection

External Backup

USB memory / HDD USB / CD-RW USB / DVR-RW USB

Internal memory

4 SATA HDD 3.5\" of up to 10 TB (not included)

Remote access

Web browser, Safire Control Center Smartphone App and PC Software

Video outputs

1 HDMI 4K, 1 VGA (independent)

Power over Ethernet

No

Disc recording mode

RAID0, RAID1, RAID5, RAID6, RAID10
