Dahua DH-PFR5QI-E60. Dahua 60m visual radar for outdoors. Radar and video integration. The high frequency radar (60GHz) is not affected by bad weather conditions. Extremely low false alarm rate. 4MP CMOS sensor, with low illumination and high definition image. Automatic and manual calibration. Support drawing protection zone in live view which can be automatically transformed into radar protection zone. Filtering human and vehicle targets. Target speed filtering with a speed of 0-40 km / h. H.265 codec, high compression rate. Built-in IR illumination up to 35 meters Dh-pfr5qi-e60.

Specifications

Radar for up to 64 targets

Radar range of up to 60 meters

Radar angle 120 ° (H), 26 ° (V)

Maximum detection speed: 43.2 km / h in continuous trace

Minimum detection speed: 0.72 km / h in continuous trace

20Hz scan frequency

Supports human and vehicle targets

Image Sensor 1 / 1.8 "4 Megapixel CMOS

Resolution: 4MP (2560x1440), 3MP (2048x1536), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720)

Video compression H.265 +, H.264 +, H.265 and H.264

Stream 1: 4MP, 3MP, 1080P, 1.3MP, 720P (1 ~ 25 ips)

Stream 2: D1, CIF (1 ~ 25 ips)

Stream 3: 1080P, 1.3MP, 720P (1 ~ 25 ips)

0.0036 lux F1.6 (color), 0.0036 lux F1.6 (B / W), 0 lux IR On

IR illumination: 4 LEDs, up to 35 meters

2.8mm fixed lens

Viewing angle: 104 ° (H), 55 ° (V), 121 ° (D)

Image modes: BLC, HLC, WDR 120dB, 2D / 3D-DNR, Defog, Image stabilization, LDC

White balance with 5 modes

Automatic and manual gain control

1 audio input / 1 output

3 alarm inputs / 2 outputs

RS485 port

MicroSD card slot up to 128GB (card not included)

Network interface: RJ45 (10/100 Base-T)

Network protocols: IPv4 / IPv6, HTTP, HTTPS, SSL, TCP / IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS , Bonjour, 802.1x

Remote viewing with browsers (IE7 and later, Chrome 45 and Firefox 46)

DSS management software

Interoperability: ONVIF S, CGI, SDK, API, Imou

Up to 20 users

Power supply: 12V DC (± 30%)

Maximum consumption: 22W

Supports PoE + (802.3 at)

Operating conditions: -40 ° C ~ + 70 ° C, relative humidity <95%

Degree of protection IP66

Metal and plastic housing

Dimensions: 160 (W) x 160 (H) x 194.4 mm
