Golmar NX3403 DISPLAY MODULE

Golmar NX3403 DISPLAY MODULE
€368.87 €567.49 Save 35%
Tax included
Reference golmar-11883405C
Brand Golmar
Quantity
In Stock

Free shipping

Golmar NX3403 DISPLAY MODULE

€368.87 €567.49 Save 35%

Golmar NX3403 DISPLAY MODULE.

NX3403 graphic display module

Reference : NX3403

Product code: 11883405C

EAN code: 8429898023281

  • For Nexa Inox plate.
  • 2mm AISI 316 stainless steel front. of thickness.
  • Requires to be combined with EL632 or EL642 sound modules (except GB2 models).
  • 128 x 64 dot yellow OLED graphic display with polycarbonate protection.
  • Navigation and call buttons.
  • PVD treatment for other finishes (gold, bronze or black) or painted in RAL® colors are available on request.

External dimensions: 100(W) x 100(H) mm.

Features

  • USB port for system programming using the "Memedit" configuration program (available for Windows® and Android® devices).
  • Transmission of the contents of the agenda to other encrypted panels and concierge units through the cables of the installation.
  • Selectable language.
  • Programmable lock release activation time between 0 and 99 seconds.
  • Cyclic presentation on the screen of the instructions for use, the time and a message to choose (eg name of the building or street).
  • Automatic programming mode and home diagnostics.
  • Possibility of assigning an access code to each of the records in the agenda. Each access code can activate a different combination of output relays (up to three) and be operational during one of the eight available time slots.

Other features

  • street signs
  • Plate design: Nexa Inox
  • Board Type : Video
  • Board Type : Audio
  • Technology : Plus
  • Plate type : Coded
