IF simulator (950-2150MHz) Televes
Designed for mitigation and flatness testing in BIS installations;Rotary switch that selects the various modes of operation,Generates a scan between 950 and 2150 MHz, thus covering all the Satellite Intermediate Band.
€293.39
Tax included
Reference
televes-4008
Brand
Televes
IF simulator (950-2150MHz) Televes
€293.39
Designed for mitigation and flatness testing in BIS installations.
Features
- Rotary switch that selects the various modes of operation.
- Generates a scan between 950 and 2150 MHz, thus covering all the Satellite Intermediate Band.
Specifications
| References | 4008 | ||
| Powering | Vdc | 12...18 | |
| Consumption | W | <2 | |
| Input connector | “F” female | ||
| Frequency range | MHz | 960-1550-2140 | |
| Accuracy | KHz | ±200 | |
| Spurious | dBc | > 20 | |
| Protection index | IP 20 | ||
