SELECT * FROM ps_od_oosbutton_manufacturer WHERE id_manufacturer = 29SELECT * FROM ps_od_oosbutton JOIN ps_od_oosbutton_lang USING (id_product) WHERE id_product = 4092 AND id_lang = 1 Ikusi MTI-900 Transmodulator DVBS/S2 a DVBT
Transmodulador DVBS/S2 ► DVBT Ikusi MTI-900
search
  • Transmodulador DVBS/S2 ► DVBT Ikusi MTI-900

Ikusi MTI-900 Transmodulator DVBS/S2 a DVBT

DVB-S / S2 to COFDM transmodulator free to air

DVB-S / S2 Single Tuner

Output on a COFDM channel

Robust before signal cuts

€931.70
Tax included
Reference ikusi-4098
Brand Ikusi
Quantity
Available in 24/48h

Free shipping
Transmodulador DVBS/S2 ► DVBT Ikusi MTI-900

Ikusi MTI-900 Transmodulator DVBS/S2 a DVBT

€931.70

Characteristics

DVB-S / S2 to COFDM transmodulator free to air

DVB-S / S2 Single Tunír

Output on a COFDM channel

Robust before signal cuts

Specs

Template MTI-900 MTI-800
REF. 4098 4099
Reception DVB-S; DVB-S2
Transport Stream Processing (TS) Yes
Common Interface (EN 50221) Yes No
Maximum number of decrypted programs Variable (depends on the CAM module) -
Input
Standard EN 300 421
Input frequency band MHz 950-2150
Input level dBm

-65 ... -25 (DVB-S)

-70 ... -25 (DVB-S2)
Input loop gain dB 0 (± 1)
CAF margin MHz ± 5
Input Rate MS / s

10 ... 30 (DVB-S2)

2 ... 45 (DVB-S)
Processing
Data Processing   EN 300 744
Operating modes   2K ,, 4K (DVB-H), 8K
Constellation   QPSK ,, 16QAM ,, 64QAM
Code rate   1/2 ,, 2/3 ,, 3/4 ,, 5/6 ,, 7/8
Guard interval   1/4 ,, 1/8 ,, 1/16 ,, 1/32
In-depth interlacing (just in DVB-H)   Applicable (in 2K and 4K modes)
Modulation error rate (MER) dB > 38 (typ.)
Output
Selectable output channel, between: MHz 47-862
Bandwidth MHz 5 (DVB-H) ,, 6 ,, 7, 8
Adjustable output level dB μ V 65 to 80
Frequency Stability ppm ≤ < 30 >
Output loop step attenuation dB 1.1
Band Spurs dBc < -50
Broadband noise (ΔB = 5 MHz) dBc < -75
General
Feeding Tension VDC + 12
Consumption mA

730 (without CAM)

870 (with CAM)

 730
Operating temperature ̊C 0 ... +45
Input RF loop connector   (2x) F female
Output RF loop connector   (2x) F female
Power connectors and telealiment. amplif.   banana socket
CAM Input   1 Slot (EN 50221) -
Programming interface   RS-232 / DB-9
IKUSUP Bus Connector   (2x) 4-pin base
Dimensions mm 230 x 195 x 32
