Triax SCT 1-16 1-output tappet, 16 dB attenuation
SCT 1-16 - 1 way tap. TRIAX coaxial tap ideal for SAT-IF and MATV distribution networks. Frequency range 5-2400 MHz. DC pass via trunk line IN-OUT. High shielding against ingress noise like radiated by LTE mobile. High quality die-cast housing tin (Sn) coated with solder shield bottom plate. Grounding clamp terminals.
€5.37
Tax included
Reference
triax-342153
Brand
Triax
Triax SCT 1-16 1-output tappet, 16 dB attenuation
€5.37
SCT 1-16 - 1 way tap
TRIAX coaxial tap ideal for SAT-IF and MATV distribution networks.
Features
- Frequency range 5-2400 MHz
- DC pass via trunk line IN-OUT
- High shielding against ingress noise like radiated by LTE mobile
- High quality die-cast housing tin (Sn) coated with solder shield bottom plate
- Grounding clamp terminals
- Formerly triax-342116
Specifications
| EAN Number | 5702663421530 |
FREQUENCY RANGE
| Frequency range | 5...2400 MHz |
OPERATIONAL
| Application | SAT-IF, MATV 2.4Ghz +DC(in<->out) |
| Screening Efficiency | EN50083-2 (Class A) |
| DC Passthrough IN-OUT | max. 1A/30V |
| Certification | EN 50581:2012 (RoHS II) |
| Environment | Indoor |
| Temperature - operating | -30…+60 °C |
LOSS
| Tap loss (in-tap) 5-40 MHz | 16.0 dB |
| Tap loss (in-tap) 40-1000 MHz | 16.0 dB |
| Tap loss (in-tap) 1000-2150 MHz | 16.0 dB |
| Tap loss (in-tap) 2150-2400 MHz | 16.0 dB |
| Insertion loss (in-out) 5-40 Mhz | 1.2 dB |
| Insertion loss (in-out) 40-1000 Mhz | 1.3 dB |
| Insertion loss (in-out) 1000-2150 MHz | 1.8 dB |
| Insertion loss (in-out) 2150-2400 Mhz | 2.3 dB |
ISOLATION
| Isolation (out-tap) 5-40 MHz | 32 dB |
| Isolation (out-tap) 40-1000 MHz | 26 dB |
| Isolation (out-tap) 1000-2150 MHz | 23 dB |
| Isolation (out-tap) 2150-2400 MHz | 23 dB |
RETURN LOSS
| Return loss (in-out) 5-40 MHz | 15.0 dB |
| Return loss (tap) 5-40 MHz | 15.0 dB |
| Return loss (in-out) 40-1000 MHz | 13.0 dB |
| Return loss (tap) 40-1000 MHz | 13.0 dB |
| Return loss (in-out) 1000-2150 MHz | 12.0 dB |
| Return loss (tap) 1000-2150 MHz | 12.0 dB |
| Return loss (in-out) 2150-2400 MHz | 10.0 dB |
| Return loss (tap) 2150-2400 MHz | 12.0 dB |
CONNECTORS
| Number of inputs | 1 |
| Number of outputs | 1 |
| Number of taps | 1 |
| Connector Type | F-female (IEC 61 169-24) |
MECHANICAL
| Main material | Zinc diecast/Sn plated |
| Packaging | Polybag |
| Packing QTY | 1 |
| Product Height | 16.5 mm |
| Product Width | 49.5 mm |
| Product Depth | 52 mm |
| Packaging Height | 0.055 m |
| Packaging Width | 0.050 m |
| Packaging Depth | 0.020 m |
| Packaging Volume | 0.000 m3 |
| Net Weight | 0.047 kg |
| Tara Weight | 0.001 kg |
| Total Weight | 0.048 kg |
ELECTRICAL
| Impedance | 75 Ω |
SHIELDING
| Shielding effeciency VHF/UHF | >85 dB |
Data sheet
- Infrared range
- 30 m
