Triax SCT 4-24 Way taps 4 outputs 24dB 5-2400 MHz
4 Way Tap of 24dB attenuation, 5-2400 MHz, F connectors, ideal for SAT-IF and MATV distribution networks.
€3.54
€7.53
Save 53%
Tax included
Reference
triax-342424
Brand
Triax
Triax SCT 4-24 Way taps 4 outputs 24dB 5-2400 MHz
€3.54
€7.53
Save 53%
Derivator with 4 outputs and 24dB attenuation, with F connectors, 5-2400 MHz, ideal for SAT-FI and MATV distribution networks.
Specifications
| Order information | |
|---|---|
| EAN number | 5702663424241 |
| Armor | |
| VHF / UHF effective shielding | > 110 dB |
| features | |
| Type | COAX shunts |
| Frequency range | |
| Frequency Range | 5 ... 2400 MHz |
| Lost | |
| Shunt losses (input-shunt) 5-40 MHz | 24.0 (± 1.2) dB |
| Shunt losses (input-shunt) 40-1000 MHz | 24.0 (± 1.2) dB |
| Shunt losses (input-shunt) 1000-2150 MHz | 24.0 (± 2.5) dB |
| Bypass losses (input-bypass) 2150-2400 MHz | 24.0 (± 2.5) dB |
| [Insertion loss (input-output)] 5-40 Mhz | 0.8 dB |
| [Insertion loss (input-output)] 40-1000 Mhz | 0.9 dB |
| [Insertion loss (input-output)] 1000-2150 Mhz | 1.8 dB |
| [Insertion loss (input-output)] 2150-2400 Mhz | 1.8 dB |
| Isolation | |
| [Isolation (bypass-bypass)] 5-40 MHz | 28 dB |
| [Isolation (output-bypass)] 5-40 MHz | 33 dB |
| [Isolation (bypass-bypass)] 40-1000 MHz | 23 dB |
| [Isolation (output-bypass)] 40-1000 MHz | 28 dB |
| [Isolation (bypass-bypass)] 1000-2150 MHz | 24 dB |
| Isolation (out-tap) 1000-2150 MHz | 2. 3 |
| [Isolation (bypass-bypass)] 2150-2400 MHz | 23 dB |
| [Isolation (output-bypass)] 2150-2400 MHz | 22 dB |
| Return loss | |
| [Return loss (input-output)] 5-40 MHz | 16.0 dB |
| [Return loss (drift)] 5-40 MHz | 15.0 dB |
| [Return loss (input-output)] 40-1000 MHz | 15.0 dB |
| [Return loss (drift)] 40-1000 MHz | 15.0 dB |
| [Return loss (input-output)] 1000-2150 MHz | 12.0 dB |
| ReturnLossTap1000to2150MHz | 13.0 |
| [Return loss (input-output)] 2150-2400 MHz | 12.0 dB |
| [Return loss (drift)] 2150-2400 MHz | 12.0 dB |
| Electrical data | |
| Impedance | 75 Ω |
| Operational | |
| Application | SAT, MATV 2.4Ghz + DC |
| Shielding efficiency | EN50083-2 (Class A) |
| DC step | Yes IN-OUT (max. 500mA) TAPS DC blocked |
| Environment | Inside |
| Connectors | |
| Number of entries | 1 |
| Number of outputs | 1 |
| Bypass number of outputs | 4 |
| Mechanic | |
| Bracket (optional) | 2x BS / Art No 342100 |
| Packaging Qty | 1 |
| Height | 57 mm |
| Width | 74 mm |
| Depth | 16 mm |
| Packing Height | 0.020 m |
| Packaging Width | 0.060 m |
| Packing Depth | 0.080 m |
| Net weight | 0.062 kg |
| Total weight | 0.062 kg |
