SELECT * FROM ps_od_oosbutton_manufacturer WHERE id_manufacturer = 22SELECT * FROM ps_od_oosbutton JOIN ps_od_oosbutton_lang USING (id_product) WHERE id_product = 437 AND id_lang = 1 Distributor 6 outputs (connector F) VFC triax SF 1061
Distribuidor 6 salidas (Conector F) VFC 1061 SF
search
  • Distribuidor 6 salidas (Conector F) VFC 1061 SF

Triax SCS 6 6-output distributor, attenuation 10 to 12 dB

SCS 6 - 6 way splitter 2.4GHz. TRIAX coaxial splitter ideal for SAT-IF and MATV distribution networks. Frequency range 5-2400 MHz. DC pass via diodes from all outputs. High shielding against ingress noise like radiated by LTE mobile. High quality die-cast housing tin (Sn) coated with solder shield bottom plate. Grounding clamp terminals.

€10.35
Tax included
Reference triax-349826
Brand Triax
Quantity
Available Now

Free shipping
Distribuidor 6 salidas (Conector F) VFC 1061 SF

Triax SCS 6 6-output distributor, attenuation 10 to 12 dB

€10.35

SCS 6 - 6 way splitter

TRIAX coaxial splitter ideal for SAT-IF and MATV distribution networks.

Features

  • Frequency range 5-2400 MHz
  • DC pass via diodes from all outputs
  • High shielding against ingress noise like radiated by LTE mobile
  • High quality die-cast housing tin (Sn) coated with solder shield bottom plate
  • Grounding clamp terminals
  • Formerly triax-349806

Specifications

INFORMACIÓN
EAN Number 5702663498266

FREQUENCY RANGE

Frequency range 5...2400 MHz

OPERATIONAL

Application SAT-IF, MATV 2.4Ghz +DC(out->in)
Screening Efficiency EN50083-2 (Class A)
DC Passthrough Yes (max. 0.5A/24V)
Certification EN 50581:2012 (RoHS II)
Environment Indoor
Temperature - operating -30…+60 °C

LOSS

Insertion loss (in-out) 5-40 Mhz 10.8 dB
Insertion loss (in-out) 40-1000 Mhz 11.5 dB
Insertion loss (in-out) 1000-2150 MHz 15.5 dB
Insertion loss (in-out) 2150-2400 Mhz 16.5 dB

ISOLATION

Isolation (tap-tap) 5-40 MHz 25 dB
Isolation (tap-tap) 40-1000 MHz 25 dB
Isolation (tap-tap) 1000-2150 MHz 23 dB
Isolation (tap-tap) 2150-2400 MHz 23 dB

RETURN LOSS

Return loss (in-out) 5-40 MHz 9.0 dB
Return loss (in-out) 40-1000 MHz 13.0 dB
Return loss (in-out) 1000-2150 MHz 12.5 dB
Return loss (in-out) 2150-2400 MHz 12.0 dB

CONNECTORS

Number of inputs 1
Number of outputs 6
Connector Type F-female (IEC 61 169-24)

MECHANICAL

Main material Zinc diecast/Sn plated
Packaging Polybag
Packing QTY 1
Product Height 47 mm
Product Width 118 mm
Product Depth 17 mm
Packaging Height 0.125 m
Packaging Width 0.070 m
Packaging Depth 0.020 m
Packaging Volume 0.000 m3
Net Weight 0.087 kg
Tara Weight 0.003 kg
Total Weight 0.090 kg

ELECTRICAL

Impedance 75 Ω

SHIELDING

Shielding effeciency VHF/UHF >85 dB
