Derivator 6 outputs (Easy clema connection) 24db EST 6-24 Triax
Derivator 6 outputs (Easy clema connection) 24db EST 6-24
€15.67
Tax included
Reference
triax-349624
Brand
Triax
Derivator 6 outputs (Easy clema connection) 24db EST 6-24 Triax
€15.67
Derivator 6 outputs (Easy clema connection) 24db EST 6-24
Specifications
| Model | EST 6-24 | |
| Code | 349624 | |
| Frequency range | MHz | 5 - 2400 |
| Nº of outputs | pcs | 6 |
| Lost in step (typical) 5 - 40 MHz | dB | 1.7 |
| 40 - 1000 MHz | dB | 2.2 |
| 1000 - 1750 MHz | dB | 2.8 |
| 1750 - 2150 MHz | dB | 3.2 |
| 2150 - 2400 MHz | dB | 3.8 |
| Lost in shunt 5 - 40 MHz | dB | 24.0 (± 1.5) |
| 40 - 1000 MHz | dB | 24.0 (± 1.5) |
| 1000 - 1750 MHz | dB | 24.0 (± 2.0) |
| 1750 - 2150 MHz | dB | 24.0 (± 2.5) |
| 2150 - 2400 MHz | dB | 24.0 (± 3.0) |
| Decoupling | dB | 22 |
| Missed return (input / output) | dB | 14 |
| Lost of return (derivation) | dB | 14 |
| Protection of the shield | dB | ≥ 110.0 |
| Current passage | Input / Output | |
| Impedance | Ohm | 75 |
| Measurements (h x d x w) | mm | 124 x 40 x 20 |
