Distributor 8 outputs (Easy terminal connection) ESS 8 Triax
Eight-way distributor with quick-connect terminal connectors. Casing made of zinc. Lightweight and compact Clone connectors. Low insertion loss. Current passage in all output ports to the input port: max. 1A, 30V.
€23.29
Tax included
Reference
triax-349508
Brand
Triax
Distributor 8 outputs (Easy terminal connection) ESS 8 Triax
€23.29
Eight-way distributor with quick-connect terminal connectors.
Features
- Casing made of zinc.
- Lightweight and compact
- Clone connectors.
- Low insertion loss.
- Current passage in all output ports to the input port: max. 1A, 30V.
Specifications
| ORDER INFORMATION | |
|---|---|
| EAN Number | 5702663495081 |
| SHIELDING | |
| Shielding effeciency VHF/UHF | > 85.0 dB |
| CHARACTERISTICS | |
| Type | COAX splitter |
| FREQUENCY | |
| Frequency range | 5...2400 MHz |
| LOSS | |
| Insertion loss (in-out) 1000-1750 Mhz | < 15.5 dB |
| Insertion loss (in-out) 1750-2150 Mhz | < 18.0 dB |
| Insertion loss (in-out) 2150-2400 Mhz | < 18.5 dB |
| Insertion loss (in-out) 40-1000 Mhz | < 13.0 dB |
| Insertion loss (in-out) 5-40 Mhz | < 12.0 dB |
| ISOLATION | |
| Isolation (out-tap) 1000-1750 MHz | > 20.0 dB |
| Isolation (tap-tap) 1750-2150 MHz | > 20.0 dB |
| Isolation (tap-tap) 2150-2400 MHz | > 20.0 dB |
| Isolation (tap-tap) 40-1000 MHz | > 21.0 dB |
| Isolation (tap-tap) 5-40 MHz | > 20.0 dB |
| RETURN LOSS | |
| Return loss (in-out) 1000-1750 MHz | > 10.0 dB |
| Return loss (in-out) 1750-2150 MHz | > 10.0 dB |
| Return loss (in-out) 2150-2400 MHz | > 10.0 dB |
| Return loss (in-out) 40-1000 MHz | > 10.0 dB |
| Return loss (in-out) 5-40 MHz | > 10.0 dB |
| ELECTRICAL | |
| Impedance | 75 Ω |
| OPERATIONAL | |
| Certification | CE |
| DC Passthrough | Yes (30VDC / 1A directed - OUT to IN) |
| CONNECTORS | |
| Connector Type | Saddle & Clamp (S&C) |
| Number of outputs | 8 |
| MECHANICAL | |
| Product Depth | 19 mm |
| Total Weight | 0,159 kg |
| Net Weight | 0,159 kg |
| Product Width | 124 mm |
| Product Height | 40 mm |
