Derivator 1 outlet (Connector F) outside/inside 16 db OTT 1-16 Triax
Derivator 1 outlet (Connector F) outside / inside 16db OTT 1-16
€4.24
Tax included
Reference
triax-349116
Brand
Triax
Derivator 1 outlet (Connector F) outside/inside 16 db OTT 1-16 Triax
€4.24
Derivator 1 outlet (Connector F) outside / inside 16db OTT 1-16
Specifications
| Model | OTT 1-16 | |
| Code | 349116 | |
| Frequency range | MHz | 5 - 2400 |
| Nº of outputs | 1 | |
| Lost in step 5 - 40 MHz | dB | < 1.0 |
| 40 - 1000 MHz | dB | < 1.2 |
| 1000 - 1750 MHz | dB | < 1.8 |
| 1750 - 2150 MHz | dB | < 2.0 |
| 2150 - 2400 MHz | dB | < 2.5 |
| Lost in derivation 5 - 40 MHz | dB | 16.0 (± 2.0) |
| 40 - 1000 MHz | dB | 16.0 (± 1.5) |
| 1000 - 1750 MHz | dB | 16.0 (± 1.5) |
| 1750 - 2150 MHz | dB | 16.0 (± 2.0) |
| 2150 - 2400 MHz | dB | 16.0 (± 2.5) |
| Decoupling | dB | > 25.0 |
| Lost of return (input / output) | dB | > 14.0 |
| Lost of return (derivation) | dB | > 12.0 |
| Protection of the shield | dB | ≥ 110.0 |
| Current passage | Input / Output | |
| Impedance | Ohm | 75 |
| Measurements (h x d x w) | mm | 74 x 40 x 20 |
