Derivator 1 output (Connector F) exterior / interior 24db OTT 1-24 Triax
Shunt 1 output (Connector F) exterior / interior 24db OTT 1-24
€2.12
€4.24
Save 50%
Tax included
Reference
triax-349124
Brand
Triax
Derivator 1 output (Connector F) exterior / interior 24db OTT 1-24 Triax
€2.12
€4.24
Save 50%
Shunt 1 output (Connector F) exterior / interior 24db OTT 1-24
Specifications
| Model | OTT 1-24 | |
| Code | 349124 | |
| Frequency range | MHz | 5 - 2400 |
| No. of outputs | 1 | |
| Lost in step 5 - 40 MHz dB | dB | < 1.0 |
| 40 - 1000 MHz | dB | < 1.0 |
| 1000 - 1750 MHz | dB | < 1.8 |
| 1750 - 2150 MHz | dB | < 2.0 |
| 2150 - 2400 MHz | dB | < 2.5 |
| Lost in shunt 5 - 40 MHz dB | dB | 24.0 (± 2.0) |
| 40 - 1000 MHz | dB | 24.0 (± 1.5) |
| 1000 - 1750 MHz | dB | 24.0 (± 1.5) |
| 1750 - 2150 MHz | dB | 24.0 (± 2.0) |
| 2150 - 2400 MHz | dB | 24.0 (± 2.5) |
| Decoupling | dB | > 35.0 |
| Missed return (input / output) | dB | > 14.0 |
| Lost of return (derivation) | dB | > 12.0 |
| Protection of the shield | dB | ≥ 110.0 |
| Current passage | Input / Output | |
| Impedance | Ohm | 75 |
| Measurements (h x d x w) mm | mm | 74 x 40 x 20 |
