2 outputs (Connector F) outdoor / indoor 10db OTT 2-10 Triax
2 outputs (Connector F) outdoor / indoor 10db OTT 2-10
€2.84
€5.69
Save 50%
Tax included
Reference
triax-349210
Brand
Triax
2 outputs (Connector F) outdoor / indoor 10db OTT 2-10 Triax
€2.84
€5.69
Save 50%
2 outputs (Connector F) outdoor / indoor 10db OTT 2-10
Specifications
| Model | OTT 2-10 | |
| Code | 349210 | |
| Frequency range | MHz | 5 - 2400 |
| No. of outputs | 2 | |
| Lost in step 5 - 40 MHz | dB | < 2.9 |
| 40 - 1000 MHz | dB | < 3.0 |
| 1000 - 1750 MHz | dB | < 4.0 |
| 1750 - 2150 MHz | dB | < 5.0 |
| 2150 - 2400 MHz | dB | < 5.5 |
| Lost in shunt 5 - 40 MHz | dB | 10.0 (± 1.5) |
| 40 - 1000 MHz | dB | 10.5 (± 1.5) |
| 1000 - 1750 MHz | dB | 10.5 (± 2.0) |
| 1750 - 2150 MHz | dB | 10.5 (± 2.0) |
| 2150 - 2400 MHz | dB | 10.5 (± 2.5) |
| Decoupling | dB | > 22 |
|
Missed input / output return |
dB | > 10.0 |
| Missing return derivation | dB | > 12.0 |
| Protection of the shield | dB | ≥ 110.0 |
| Current passage | Input / Output | |
| Impedance | Ohm | 75 |
| Measurements (h x d x w) | mm | 95 x 40 x 20 |
