• -53%
Derivador 4 salidas (Conector F) exterior/interior 12db OTT 4-12
search
  • Derivador 4 salidas (Conector F) exterior/interior 12db OTT 4-12

Shunt 4 outlets (Connector F) outside / inside 12db OTT 4-12 Triax

Shunt 4 outputs (Connector F) outside / inside 12db OTT 4-12

€3.92 €8.35 Save 53%
Tax included
Reference triax-349412
Brand Triax
Quantity
Available Now

Free shipping
Derivador 4 salidas (Conector F) exterior/interior 12db OTT 4-12

Shunt 4 outlets (Connector F) outside / inside 12db OTT 4-12 Triax

€3.92 €8.35 Save 53%

Shunt 4 outlets (Connector F) outside / inside 12db OTT 4-12

Specifications

Model   OTT 4-12
Code   349412
Frequency range MHz 5 - 2400
No. of outputs pcs 4
Lost in step                      5 - 40 MHz dB < 4.3
40 - 1000 MHz dB < 4.5
1000 - 1750 MHz dB < 5.0
1750 - 2150 MHz dB < 5.5
2150 - 2400 MHz dB < 6.0
Lost in derivation             5 - 40 MHz dB 12.0 (± 2.0)
40 - 1000 MHz dB 12.0 (± 1.5)
1000 - 1750 MHz dB 12.0 (± 1.5)
1750 - 2150 MHz dB 12.0 (± 2.0)
2150 - 2400 MHz dB 12.0 (± 2.0)
Decoupling dB 22
Lost of return (in / out) dB 12
Lost of return (derivation) dB 14
Protection of the shield dB ≥ 110.0
Current passage   Input / output
Impedance Ohm 75
Measurements (h x d x w) mm 162 x 40 x 20
