Outlet 4 outlets (Connector F) outdoor / indoor 20db OTT 4-20 Triax
Outlet 4 outlets (Connector F) outdoor / indoor 20db OTT 4-20
€4.17
€8.35
Save 50%
Tax included
Reference
triax-349420
Brand
Triax
Outlet 4 outlets (Connector F) outdoor / indoor 20db OTT 4-20 Triax
€4.17
€8.35
Save 50%
Outlet 4 outlets (Connector F) outdoor / indoor 20db OTT 4-20
Specifications
| Model | OTT 4-20 | |
| Code | 349420 | |
| Frequency range | MHz | 5 - 2400 |
| No. of outputs | pcs | 4 |
| Lost in step 5 - 40 MHz dB | dB | < 1.5 |
| 40 - 1000 MHz | dB | < 1.8 |
| 1000 - 1750 MHz | dB | < 2.2 |
| 1750 - 2150 MHz | dB | < 2.5 |
| 2150 - 2400 MHz | dB | < 3.0 |
| Lost in shunt 5 - 40 MHz dB | dB | 20.0 (± 2.0) |
| 40 - 1000 MHz | dB | 20.0 (± 1.5) |
| 1000 - 1750 MHz | dB | 20.0 (± 1.5) |
| 1750 - 2150 MHz | dB | 20.0 (± 2.0) |
| 2150 - 2400 MHz | dB | 20.0 (± 2.5) |
| Decoupling | dB | 22 |
| Lost of return (input / output) | dB | 14 |
| Lost of return (derivation) | dB | 14 |
| Protection of the shield | dB | ≥ 110.0 |
| Current passage | Input / Output | |
| Impedance | Ohm | 75 |
| Measurements (h x d x w) | mm | 162 x 40 x 20 |
