Distributor PAU series EST (Clema easy) 2 inputs / 6 asymmetric outputs Triax
Distributor PAU series EST (Clema easy) 2 inputs / 6 asymmetric outputs. Frequency range MHz 5 - 2400. Impedance Ohm 75
€20.84
Tax included
Reference
triax-349551
Brand
Triax
Distributor PAU series EST (Clema easy) 2 inputs / 6 asymmetric outputs Triax
€20.84
Distributor PAU series EST (Clema easy) 2 inputs / 6 asymmetric outputs
Specifications
| Model | EST-PAU1061 | |
| Code | 349561 | |
| Frequency range | MHz | 5 - 2400 |
| Nº of inputs | 2 | |
| Nº of outputs | 6 Asymmetric | |
| Lost in distribution 5 - 40 MHz | dB | 11.0 (S 1-2) / 11.0 (S3...6) |
| 40 - 1000 MHz | dB | 12.0 (S 1-2) / 12.0 (S3...6) |
| 1000 - 1750 MHz | dB | 12.5 (S 1-2) / 13.5 (S3...6) |
| 1750 - 2150 MHz | dB | 12.5 (S 1-2) / 15.5 (S3...6) |
| 2150 - 2400 MHz | dB | 12.5 (S 1-2) / 17.0 (S3...6) |
| Decoupling output / output | dB | > 21.0 |
| Losses of return (input) | dB | > 11.0 |
| Lost of return (output) | dB | > 11.0 |
| Protection of the shield | dB | ≥ 110.0 |
| Current passage | All | |
| Impedance | Ohm | 75 |
| Measurements (h x d x w) | mm | 125x40x20 |
