Ikusi UDB-410 Tap 4 outputs 10 dB FAST

Passive quick connection elements ideal for ICT installations. Inside. 4 outputs. Bypass attenuation 10 dB. Quick and safe connection without connectors thanks to a flange system. Low insertion losses. Zamak chassis with high quality armor. Provision for grounding.

€24.07
Tax included
Reference ikusi-2117
Brand Ikusi
Quantity
Available in 24/48h

Free shipping
Mast clamp for window Televes

Ikusi UDB-410 Tap 4 outputs 10 dB FAST

€24.07

IKUSI UDB-410. Passive quick-connect elements

Features

  • 1, 2, 4, 6 and 8-way shielded directional tap-offs. 5-2400 MHz
  • Fast and safe connection without the need for connectors
  • Low insertion loss
  • Zamak chassis with high-quality shielding
  • Grounding facilities

Technical specifications

REF. 2117 2118 2119 2120
Number of outputs 4
Frequency range MHz
Tap-off loss (± 1 dB) dB 10 15 20 25
Through loss 5-862 MHz dB ≤4,0 ≤2,2 ≤0,9 ≤0,7
862 -2150 MHz ≤4,8 ≤3,5 ≤2,5 ≤0,7
2150-2400 Mhz ≤5,2 ≤4,5 ≤3,0 ≤0,8
Directional isolation 5-862 MHz dB ≥33 ≥34 ≥38 ≥45
862 -2150 MHz ≥32 ≥33 ≥30 ≥39
2150-2400 Mhz ≥26 ≥25 ≥23 ≥34
Tap-to-tap isolation 5-862 MHz dB ≥28 ≥30 ≥30 ≥35
862 -2150 MHz ≥26 ≥28 ≥29 ≥33
2150-2400 Mhz ≥24 ≥25 ≥25 ≥30

Manual/Datasheet
