Channel Selection Geometry (CSG) technology

CSG Technology (geometry channel selection) is a new concept in the design and manufacture of antennas TV antenna giving the adjustable filter paper by changing its shape (geometry).

Three antennas in a. Changing the position of the directors to change the frequency response of the antenna, positioning the upper limit of the band on channel 58 or 59 or 60.

Highlights

•     Special double "U" that allows adjustment of the frequency response by opening the directors dipole.
•     10 reflector elements.
•     Innovative fast and safe assembly of the spotlight.
•     Made of high quality aluminum that ensures long life.

Features

•     Valid for any channel map of the Digital Dividend, regardless of the upper cutting channel Antena.
•     Robust and lightweight.
•     Flatness in band.

Specifications

Reference			149202
Mode
Work band		MHz	470-774 CH 21-58	470-782 CH 21-59	470-790 CH 21-60
Gain		dBi	15
Front-to-Backratio		dB	23
Wind load	130 Km/h	N	93
	150 Km/h		128
