Encoder Modulador DVBT/DVBC QUAD compound (QAM Annex A) Televes
search
  • Encoder Modulador DVBT/DVBC QUAD compound (QAM Annex A) Televes

Encoder Modulador DVBT/DVBC QUAD compound (QAM Annex A) Televes

The content generated consists of up to four services since it has four analog composite video inputs (CVBS). They generate DVBT, DVBC (QAM Annex A) or ITUJ83 (QAM Annex B) output. These modules can encode the video in MPEG-2 format or in H.264 (HDTV). Televes 563822

€1,974.72
Tax included
Reference televes-563822
Brand Televes
Quantity
Available in 24/48h

Free shipping
Encoder Modulador DVBT/DVBC QUAD compound (QAM Annex A) Televes

Encoder Modulador DVBT/DVBC QUAD compound (QAM Annex A) Televes

€1,974.72

The content generated consists of up to four services since it has four analog composite video inputs (CVBS). They generate DVBT, DVBC (QAM Annex A) or ITUJ83 (QAM Annex B) output. These modules can encode the video in MPEG-2 format or in H.264 (HDTV).

Stands out for

  • Perfect synchronization between image and audio
  • Compatibility with multiple TV formats, resolutions and sizes
  • Editing of all modulation parameters and signal coding
  • Configurable through web interface and with a PCT5.0 programmer
  • High output power without the need for an extra amplifier
  • Standard multi output format
  • Excellent output quality (MER> 40dB)
  • Led diodes for device monitoring and signal status
  • Energy efficient due to its low consumption
  • Integrated RF combiner and Ethernet switch
  • Automatic and remote firmware update
  • Configuration via web interface embedded in the encoder

Features

  • Multiple types of input signals: HDMI, CVBS, YPbPr, SPdIf audio (ref.563832), etc.
  • HDCP (High-bandwidth digital Content Protection) feature that can be disabled by the property with authorization from the content provider

Specifications

Reference 563822
INPUTS
Video 4 groups 1 x
RCA (CVBS)
Audio 4 grupos 2 x
RCA (L, R)
Video + Audio -
VIDEO ENCODER Output format MPEG-2 / H264
Resolution 480i & 576iAuto-scan of the input resolution
Aspect ratio 4:3, 16:9 y pass through
GOP 10, 12, 15, 16, 18, 20, 24 ó 30
AUDIO ENCODER Output format MPEG1 Layer 2
Sampling rate kHz 48
OUTPUT Frequency band MHz 46...862
Maximum output level dBμV 115 (103 with output loop activated)
MER dB >40
Spurious dBc -60
QAM
Modulation 16, 32, 64, 128, 256
BaudRate Mbaud 6.9
Roll-off % 15
Code Reed Solomon
Spectrum mode Normal / Inverted
Frequent steps kHz 250
COFDM
Modulation QPSK, 16QAM, 64QAM
Guard interval μS
FEC 1/2, 2/3, 3/4, 5/6, 7/8
Bandwidth MHz
Cell_id Editable
Frequent steps KHz
PSI
Transport Stream ID Editable
Original Network ID Editable
Network ID Editable
LCN Editable
NIT Manual / Automatic
SDT Manual / Automatic
Tipo LCN Generic / UK / NorDig V1 / NorDig V2
Network Name Editable
Service PID Editable
Service Name Editable
Service ID Editable
GENERAL
Supply voltage Vdc 24
Consumption W < 16
Protection Index IP 20
