Fte MA HD 35 Smatv amplifier
Smatv amplifier MA FI 35. 2 inputs (1 ter, 1 sat) and 1 output. Frequency range Ter: 47 - 862 MHz, Sat: 950 - 2150 MHz. Gain Ter: - 2.5 dB, Sat: 32 - 42 dB. LNC power: 13 V - 250mA. Consumption: 230Vac - 50Hz, 13.2W
€129.71
Tax included
Reference
fte-0304035
Brand
Fte
Fte MA HD 35 Smatv amplifier
€129.71
Smatv amplifier
Specifications
| Model | MA HD 35 | |
| Code | 0304035 | |
| Number of inputs | 3: 1x VHF / 1x UHF / 1x SAT | |
| Number of outputs | 1 | |
| Frequency range | VHF | 47-230 MHz |
| UHF | 470-782 MHz | |
| SAT | 950-2150 MHz | |
| Gain | VHF | 30 dB |
| UHF | 42 dB | |
| SAT | 32-42 dB | |
| Gain regulation | VHF | 20 dB |
| UHF | 20 dB | |
| SAT | 15 dB | |
| Equalization | SAT | 10 dB |
| Max output level | VHF | 122 dBμV |
| UHF | 122 dBμV | |
| SAT | 122 dBμV | |
| Power for previous UHF input | 24Vdc / 120 mA | |
| LNB power | 13 Vdc / 300 mA | |
| Consumption | 230 Vac-50 Hz, 9.5W * | |
| Dimensions | 250 x 131 x 65 mm | |
| Operating temperature | 0-40 Cº |
* No LNB consumption or mast preamp
