Triax DAP 910 Satellite dish 90cm RAL 1013 White
search
  • Triax DAP 910 Satellite dish 90cm RAL 1013 White

Triax DAP 910 Satellite dish 90cm RAL 1013 White

Fiberglass dishes are the preferred option in some markets. The most durable long-term solutions in difficult environments, for example, in coastal areas or mountainous regions. Efficiency 70. Elevation range 10-55 °. Angle of travel 26 °. Polarization X > 27 dB. Type DAP 910. Color White.

€340.62
Tax included
Reference triax-362910
Brand Triax
Quantity
Available in 4/5 days

Free shipping
Triax DAP 910 Satellite dish 90cm RAL 1013 White

Triax DAP 910 Satellite dish 90cm RAL 1013 White

€340.62

This product is not sent to some countries or areas, if the cart does not have available carriers, you can contact us here

DAP 910 - RAL 1013. Fibre glass dishes are the preferred choice in some markets. The most durable long-term solutions in difficult environments, for example in coastal areas or mountain regions.

Specifications

ORDER INFORMATION
EAN Number 3700113427936
CHARACTERISTICS
Efficiency 70
Elevation range 10-55 °
Offset angle 26 °
X-polarisation > 27 dB
Type DAP 910
FREQUENCY
Frequency range 10.7 - 12.75 GHz
GAIN
Gain @ 12.625 GHz 39.7 dBi
Noise temperature < 35 °K
Gain @ 11.7 GHz 39.0 dBi
MECHANICAL
Finish Alu arm
Packaging Depth 0.006 m
Packaging Height 0.001 m
Total Weight

8.940 kg
Packaging Width 0.007 m
LNB holder Plastic
LNB size Ø 40 mm
Mast bracket diameter Ø 50-60 mm
Net Weight 8.940 kg
Reflector type Offset
Remarks 2 U-Bolt for mast mount 6° Multifeed MFD850 P/N 200251
Windload @ 42 m/s 846 N
Width (cm) 94 cm
Height (cm) 86 cm
Colour RAL 1013 - White
Product Height 940 mm
Product Length 860 mm
Main material Fibreglass
