Ikusi SZB-129 High gain single-channel amplifier FM SZB

Modular Headend amplifier channel TV and Radio. TV amplifiers single-channels, multichannels, modulators and Sat-IF combiner ready for digital dividend.

€81.07

Tax included

Reference ikusi-2294

Brand Ikusi

Ikusi SZB-129 High gain single-channel amplifier FM SZB

€81.07

Description
Product Details

IKUSI SZB-129. Modular Headend amplifier channel TV and Radio. TV amplifiers single-channels, multichannels, modulators and Sat-IF combiner ready for digital dividend.

Features

TV single-channel amplifiers, Z input de-multiplexing and Z output multiplexing. Adjacent channel operation allowed in UHF band.
FM Radio and DAB Amplifiers.
It is advisable to place the amplifiers on the base-plate following an increasing order of number of channel (frequency). The RF output of the headend will be taken from the last one of the modules ordered in this way.
Especially created for amplification of combined analog and digital channels.
Output voltage +24 VDC is automatically connected to the RF modules through a connecting bar at the base-plate.
Toolless mounting.

Technical specifications

REF.		2294	2293	3160	3152	2246
Bandwidith		FM	FM	DAB	1 channel BIII ¹	1 channel UHF ²
Gain ^{3 , 4}	dB	57	30	53	56	52
Noise figure	dB	4	7,5	8	7	9
Output level EN 50083-3, -35dB	dBµV	(2x) 113 IMD -50dB			(2x) 121
Z output return loss	dB	≥ 6
Consumption	mA	100	80	100	100	100
Dimensions	mm	190 x 38 x 87
