Ikusi ATP-190-C48 Amplifier 1 input 1 output terrestrial/satellite 47-694 MHz
Apartament amplifiers ATP190 series. Models for terrestrial and satellite signals, adapted to the 1st and 2nd Digital Dividend.
€47.80
Tax included
Reference
ikusi-3590
Brand
Ikusi
Ikusi ATP-190-C48 Amplifier 1 input 1 output terrestrial/satellite 47-694 MHz
€47.80
IKUSI ATP-190-C48. Apartament amplifiers ATP190 series. Models for terrestrial and satellite signals, adapted to the 1st and 2nd Digital Dividend.
Features
- Models adapted to the 1st and 2nd Digital Dividend.
- Terrestrial and satellite outputs.
- Gain adjustment potentiometers.
- Return path.
- DC transit.
Technical specifications
| Model ATP190-C60 ATP190-C48 |
Ref. | ATP190 series | ||
| 3589 | Frequencies MHz | 47 - 790 | 950 - 2400 | |
| 3590 | 47 - 694 | |||
| Input | 1 | |||
| Output | 1 | |||
| Gain | dB | Terr: >18 | Sat: >22 | |
| Gain adjustment | dB | Terr: >10 | - | |
| Output level | dBμV | Terr: 106 IMD3 -60dB (DIN 45004B) |
Sat: 112 IMD3 -35dB (EN 50083-3) |
|
| Return path frequency | MHz | 5 - 30 | ||
| Noise figure | dB | <5 | <6 | |
| Mains supply voltage | VAC | 100 - 240 | ||
| DC transit | mA | 500 | ||
| Consumption | W | <3 | ||
| Dimensions | mm | 135 x70 x 30 | ||
