Data sheet

Weight

2.5Kg
125 g

Dimensions

110x16 mm
370 x 410 x 80 mm

Temperature

-5ºC~+45ºC

Compatibility

AXIS Series

Colour

White

Primary power supply

Switching source 187-252V AC 50-60 Hz 65W max.

Backup power supply

2 batteries 12VDC (up to 18 Ah). Ensures minimum 72 hours duration.

Number of zones

24 zones, up to 30 detectors by area.

Siren outputs

2 siren outputs 24VDC. Independent and monitored open collector outputs

Relay outputs

12 Relay outputs: [VAR%] Alarm output, 1 Fault output and 1 configurable relay outputs. All support 30VDC 3A max.

End of line resistance

Areas fully monitored by end-of-line resistance (4.7K)

Auxiliary Output Voltage

24VDC. Protected by resettable electronic fuse 1.85A

Protection Index

IP30

Material and colour

ABS, colour: White

Recommended cable

Fire cable with a minimum section of 1.0mm (18AWG).

Use

Valid for interior/exterior

Composition

Aluminium alloy and steel

Available languages

Spanish, English, Portuguese, Italian, French, and German.

Assembly area

130mm (H) x 140mm (W)
