Data sheet

Weight

1,3Kg
125 g

Dimensions

58 x 100 mm (H x D) / 130g
310 x 240 x 80 mm

Temperature

-5ºC~+45ºC

Colour

Black

IP protection

IP40

Primary power supply

Switching source 187-252V AC 50-60 Hz 65W max.

Backup power supply

2 batteries 12VDC (up to 5 Ah). Ensures minimum 72 hours duration.

Number of zones

8 zones, up to 30 detectors by area.

Siren outputs

2 siren outputs 24VDC. Independent and monitored open collector outputs

Relay outputs

4 Relay outputs: [VAR%] Alarm output, 1 Fault output and 1 configurable relay outputs. All support 30VDC 3A max.

End of line resistance

Areas fully monitored by end-of-line resistance (4.7K)

Auxiliary Output Voltage

24VDC. Protected by resettable electronic fuse 1.85A

Protection Index

IP30

Material and colour

ABS, colour: White

Recommended cable

Fire cable with a minimum section of 1.0mm (18AWG).

Use

Valid for interior/exterior

Composition

Aluminium alloy and steel

Certification

EN54-5, EN 54-7 and EN54-17

Series

AXIS

Consumption standby mode (Max.)

85μA

Consumption alarm (Max.)

20mA@24VDC

Voltage DC

Nominal Relay Switching current 24V (18~40V)

Available languages

Spanish, English, Portuguese, Italian, French, and German.

Alarm thresholds

Up to 4 selectable alarm thresholds

Operating temperature range

-10ºC ~ +55ºC

Humidity (non condensing)

95% RH

Assembly area

130mm (H) x 140mm (W)
