Data sheet

Weight

600 g

Power

DC 12V / 462mA max., PoE IEEE802.3af

Temp. operation

-30º C ~ +60º C

Dimensions

41.2 (H) x 119.9 (Ø) mm

Transfer Rate

32 Kbps ~ 8 Mbps

Dimensions / Weight

25 (D) x 10 (W) mm / 5 g

Compatibility

Microcoaxial cable and RG59

Connection type

BNC male for crimp

Image sensor

1/1.3\" Progressive Scan CMOS

Minimum illumination

0.01 Lux (F1.2)

Basic functions

OSD Menu

Lens

Lens 1.6 mm Fisheye

Maximum resolution

2560x1440 (4 MP)

Image improvements

3D-NR, BLC, AWB, AGC, ROI, Defog

Day / Night

Removable mechanical ICR filter

Alarms

1 inputs / 1 relay

Internal memory

MicroSD card up to 128GB (not included)

Remote access

Web browser, Safire Control Center Smartphone App and PC Software

Main Stream rate

12.5fps(2560 × 1440), 25fps(1920 × 1080, 1280 × 720)

Compression

H.264/MJPEG

Network interface

Ethernet 10/100/1000 BaseT

Video analysis

VCA: Cross-line, intrusion detection, area entry/exit detection, removed/abandoned object detection Intersection analysis: Detects and analyzes flow in an intersection-like scene and generates reports. Supports intersection up to 10 shapes

Interoperability

HIKVISION, ONVIF, PSIA, CGI, ISAPI

Display modes

16 visualisation modes supported, including image correction/de-warping Views: Fisheye, panoramic, up to 8 ePTZ and various combinations
