Data sheet

Power

DC 12 V ± 20%

Battery

Lithium 20Ah / 10.8V

Temp. operation

-30º C ~ +60º C

Degree of protection

Weatherproof IP67

Material

Front cover: Metal / Camera body: Plastic

Compatibility

UTP Cables

Audio

No

Connection type

RJ45

Consumption

1. The average power consumption of 24 hours is 1,76 W (transmission 4G is excluded, 50% lighting) 2. On rainy or cloudy days, the battery life of the camera is up to 5.2 days if it has been fully charged (if the camera operates continuously according t

Camera dimensions

760 mm x 732.6 x 586.9 mm (maximum camera size after complete assembly)

Image sensor

1/2.8\" Progressive Scan CMOS

Minimum illumination

Colour: 0.004 Lux @(F1.4, AGC ON) B/W: 0.002 Lux @(F1.4, AGC ON)

Lens

2.8 mm

Maximum resolution

2 Megapixel (1920x1080)

Infrared lighting

0 Lux / Matrix LED IR (30 m)

Image improvements

WDR, BLC, 3D-DNR, MD, Privacy Mask, ROI, Defog

Day / Night

Auto / Programmable / Colour / BW (Black and White)

Alarms

No

Internal memory

Micro SD slot (up to 256GB))

Remote access

Web browser, Safire Control Center Smartphone App and PC Software

Main Stream rate

(1920×1080, 1280×960, 1280×720) (1~25FPS)

Extra Stream rate

(704×576, 640×480) (1~25 FPS)

Compression

H.265+/H.265/H.264+/H.264

Network interface

Ethernet 10/100 4G Micro SIM card (LTE-TDD/LTE-FDD/WCDMA/GSM)

Category

6

Interoperability

ONVIF, PSIA, CGI, ISAPI

Video Bit Rate

32 Kbps~8Mbps

Camera weight

12964 g
