Data sheet

Weight

1740 g

Power

DC 12 V / 1 A, PoE IEEE802.3at / 0.3A

Temp. operation

-30º C ~ +60º C

Degree of protection

Waterproof IP67, TVS 4000V

Dimensions

386 (D) x 156 (W) x 155 (H) mm

Transfer Rate

32 Kbps ~ 16 Mbps

Video output

1 composite video output (BNC connector)

Audio

1 input (line in / microphone ), 1 output

Connection type

RJ45

Image sensor

1/2.5\" Progressive Scan CMOS

Minimum illumination

0 Lux / IR LEDs (120 m)

Lens

4.7~65.8mm Motorised auto-focus

Maximum resolution

4 Megapixel (2560x1440)

Image improvements

WDR (105 dB), BLC, 3D-NR, AWB, Privacy Masking, ROI, Hall Mode

Day / Night

Removable mechanical ICR filter

Alarms

1 Input / 1 Relay

Internal memory

MicroSD card, Max 128 GB

Remote access

Web browser, Safire Control Center Smartphone App and PC Software

Main Stream rate

25fps (2560 × 1440, 2304 × 1296, 1920 1080, × 1280 960, × 1280 720) × [%VAR%]

Extra Stream rate

25fps (640 × 480, 640 × 360, 320 × 240

Compression

H.265+ / H265 /H.264+ / H264 / MJPEG

Category

6A

Interoperability

ONVIF, PSIA, CGI

Smart Features

Line Crossing, Area Intrusion, Region Entry Detection, Region Exit Detection, Removed Object Detection, Abandoned Object Detection, Face Detection, Counting Statistics, etc

Third Stream Rate

25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 640 × 360, 352 × 288, 320 × 240)

Communication interface

Ethernet 10/100M BaseT | 1 RS485
