Data sheet

Weight

54 g
350 g
388 g
400 g

Power

DC 12 V / 1A max. / (802.3af) PoE or 2 wires via hub
DC 12 V / 1A max. / (802.3af) PoE or 2 wires via hub
DC 12 V / 500 mA max. / PoE (802.3af)
DC 48 V / 1-3 A max.

Temp. operation

-10º C ~ +55º C
-30º C ~ +60º C

Degree of protection

IP55, IK07

Dimensions

54 (D) x 34.9 (Ø) mm
129mm (H) x 95mm (W) x 28,5mm (Fo)/td≥
130 (H) x 96 (W) x 28.5 (D) mm
130 (H) x 189 (W) x 26.9 (D) mm
131 (H) x 103 (W) x 40 (D) mm

Operating temperature

-30ºC ~ 70ºC

Inputs

1 alarm, 1 door status, 1 Eoc, 1 push button
6 Configurable alarm inputs / bell output

Outputs

1 for lock control, 1 alarm, 1 tamper, 1 12V/100mA output
3 groups of 2 wires

Material

Aluminium alloy
Aluminum Alloy

Mounting

Wall surface
Wall surface

Communication

Technology 2-hilos (Up to 20 monitors and 2 boards) | Up to 10 cascading levels

Audio

Bidirectional audio with microphone and speaker
Two-way audio with microphone and speaker with noise cancellation

Video format

1/2.7\"

Operating system

LINUX OS

Memory

Supports MicroSD up to 64 GB

Image sensor

2 MP CMOS HD low light

Lens

2 mm

Viewing angle

D: 120º H:160º

Remote access

DMSS mobile phone application or DSS Express software
Web browser, Mobile App or SmartPSS software

Network interface

Ethernet 10/100 BaseT
Ethernet 10/100 BaseT and 2 wires

Focal length

3~9 mm

Aperture

F1.6

Quality

3.0 Megapíxel

Iris control

DC (AutoIris)

Thread type

CS

Connection

2 x RJ45

LCD

7\" TFT 1024x600, Capacitive
7\" TFT 1024x600, Capacitive

Operation mode

Power, Video & Audio all via the 2 wire technology
Tactile Buttons

Keypad

Mechanical button with LED backlit name-tag
