Data sheet

Weight

1900 g

Power

12VDC / 5W, PoE IEEE802.3at

Temp. operation

-40º C ~ +60º C

Degree of protection

Weatherproof IP66

Dimensions

388 mm (D) x 110 (Ø) mm

Alarm

2/2 In/Out

Audio

1 input / 1 output line level 600 ohm

Lens

35 mm

Viewing angle

11º x 9º

Internal memory

Micro SD card up to 128GB

Remote access

WEB interface, CMS (SunView), Smartphone and NVR

Main Stream rate

D1 (25fps)

Extra Stream rate

VAT NUMBER (25fps)

Compression

H.265 / H.264 / MJPEG

Network interface

Ethernet 10/100 BaseT

Interoperability

ONVIF

Intelligent functions

Detection of fire and alarm, line crossing, intrusion

Thermal sensor

400x300 VOx

VCA ranges

Fire detection: 1029 m Person detection: 1029 m Vehicle detection: 3137 m Fire recognition: 343 m Person recognition: 257 m Vehicle recognition: 789 m
Fire detection: 1029 m Person detection: 1029 m Vehicle detection: 3137 m Fire recognition: 343 m Person recognition: 257 m Vehicle recognition: 789 m

Thermal sensitivity

≤40mK

Spectral range

8~14um

VCA

Up to 8 VCA rules (cross line, intrusion, area entry and exit)

Temperature rules

Even 19 rules (9 points, 9 areas and 1 line)

Range of Detectable Temperatures

-40 ℃ to 150 ℃ ( from -4 ℉ to ℉ 302 )
