Wooden coil 250m Coaxial Cable TR-165 LSFH UV Resistant Dca Class A 11RtC Ø 1.63/7.2/10.1mm Gray Televes

Coaxial cable with both conductors made of copper 100% (Cu/Cu) and excellent braid coverage (77%). Includes a petro-gel layer and an external UV-resistant LSFH coverage, perfect for indoor and outdoor installation, specially for underground use, free of deformations and degradations that could affect the quality of the transported signal. An 11 RtC cable with double shielded.

€113.26 €174.24 Save 35%
Tax included
Reference televes-214911
Brand Televes
Quantity
Out-of-Stock

Free shipping

You might also like

Coaxial cable with both conductors made of copper 100% (Cu/Cu) and excellent braid coverage (77%). Includes a petro-gel layer and an external UV-resistant LSFH coverage, which makes it perfect for indoor and outdoor installation, specially for underground use, free of deformations and degradations that could affect the quality of the transported signal. An 11 RtC cable with double shielded.

Stands out for

  • Copper conductors
  • Class A shielded
  • Dca-s2,d2,a1 Euroclass
  • Petro-gel layer

Main Features

  • Grey-colour external UV-resistant LSFH sheath
  • 75 Ohm characteristic impedance
  • 250m wooden reel

Discover

Class A double layer coaxial cable

With 2 layers of shielding, these cables offer good shielding thanks to a high coverage mesh.

Their constructive properties make them Class A, complying according to the EN 50117 standard:

  • At 5 - 30 MHz => TI <5 m="" li="">
  • At 5 - 1000 MHz => SA> 85 dB
  • At 1000 - 2000 MHz => SA> 75 dB
  • At 2000 - 3000 MHz => SA> 65 dB

Where, the transfer impedance (TI) defines the effectiveness of the shielding at low frequencies, and the shield attenuation (SA) defines it between 30 and 3000MHz.

Specifications

Type TR-165
Standard EN 50117-2-5
Euroclass Dca
Euroclass: Smoke Production s2
Euroclass: Flaming droplets d2
Euroclass: Acidity a1
Class A
Inner conductor Diameter mm 1.63
Inner conductor Material Copper (Cu)
Inner conductor Resistance Ω/km <9
Dielectric Diameter mm 7.2
Dielectric Material Foam polyethylene (PEE)
Dielectric Color White RAL 9003
Overlapped foil Aluminium + Polypropylene + Aluminium
Braid Material Copper
Braid dimensions: No. of carriers (Nc) 16
Braid Dimensions: No. of strands per carrier (Ns) 8
Braid Dimensions: strand diameter (Ø) mm 0.148
Braid Resistance Ω/km <7.2
Braid Coverage % 77
2nd foil No
2nd foil glued to the dielectric No
Petrol-Jelly Yes
Anti-migrating film No
Outer sheath Diameter mm 10.1
Outer sheath Material LSFH, UV-resistant
Outer sheath Thickness mm 1
Minimum bending radius mm 50
Transfer impedance (5-30MHz) mΩ/m <5
1GHz shielding dB > 85
Spark Test Vac 8000
Capacitance pF/m 53
Impedance Ω 75
Velocity ratio % 84
Operating temperature °C -25 ... 70
Frequencies
5 MHz 47 MHz 54 MHz 90 MHz 200 MHz 500 MHz 698 MHz 800 MHz 862 MHz 950 MHz 1000 MHz 1220 MHz 1350 MHz 1750 MHz 2050 MHz 2150 MHz 2200 MHz 2300 MHz 2400 MHz 3000 MHz
Attenuation (typ.) dB/m
0.01 0.03 0.03 0.04 0.06 0.09 0.1 0.11 0.12 0.12 0.13 0.14 0.15 0.18 0.19 0.2 0.19 0.21 0.21 0.24
