Wooden coil 250m Coaxial Cable T-100 LSFH Dca Class A 16AtC Ø 1,13/4,7/6,6mm Gray Televes

Live coaxial cable made of copper and aluminum mesh (Cu/Al), with excellent braiding coverage (77%). One 16AtC cable, double shielded and LSFH sheath.

€3,967.11 €6,103.24 Save 35%
Tax included
Reference televes-212661
Brand Televes
Quantity
Available in 24/48h

Free shipping
MNT22-FHD - Full HD LED 21.5\" monitor, Designed for surveillance…

Wooden coil 250m Coaxial Cable T-100 LSFH Dca Class A 16AtC Ø 1,13/4,7/6,6mm Gray Televes

€3,967.11 €6,103.24 Save 35%

Live coaxial cable made of copper and aluminum mesh (Cu/Al), with excellent braiding coverage (77%). One 16AtC cable, double shielded and LSFH sheath.

Stands out for

  • Internal conductor made of copper and aluminum mesh
  • Class A shielding
  • Euroclass Dca

Characteristics

  • LSFH exterior coverage in gray
  • 75 ohm characteristic impedance
  • 250m wooden spool

Class A double layer coaxial cable

With 2 layers of shielding, these cables offer good shielding thanks to a high coverage mesh.

Their constructive properties make them Class A, complying according to the EN 50117 standard:

  • At 5 - 30 MHz => TI 5 mΩ/m
  • At 5 - 1000 MHz => SA> 85 dB
  • At 1000 - 2000 MHz => SA> 75 dB
  • At 2000 - 3000 MHz => SA> 65 dB

Where, the transfer impedance (TI) defines the effectiveness of the shielding at low frequencies, and the shield attenuation (SA) defines it between 30 and 3000MHz.

Specifications

Guy T-100
Standard EN 50117-2-4
Euroclass Dca
Euroclass: Emission of opaque fumes s2
Euroclass: Falling Flammable Particles d2
Euroclass: Acidity a1
Class TO
Central Conductor Diameter mm 1.13
Central Conductor Material Copper (Cu)
Central conductor resistance Ω / km <20
Dielectric Diameter mm 4.7
Dielectric Material Expanded Polyethylene (PEE)
Dielectric Color White RAL 9003
Inner foil Aluminum + Polyester + Aluminum
Mesh Material Aluminum
Mesh dimensions: number of yarns groups (Nc) 16
Mesh Dimensions: number of threads per group (Ns) 8
Mesh dimensions: wire diameter (Ø) mm 0.12
Mesh resistance Ω / km <27
Mesh coverage % 76
2nd shield sheet No
2nd shielding sheet glued to the dielectric No
Petro-Gel No
Anti-migration sheet No
Outer cover diameter mm 6.6
Material Outer cover LSFH
Thickness Outer Cover mm 0.3
Minimum bend radius mm 33
Transfer impedance (5-30MHz) mΩ / m <5
1GHz shielding dB > 85
Spark Test Vac 3000
Capacity pF / m 52
Impedance Ω 75
Propagation velocity min. % 85
Operating temperature ° C -25 ... 70
Frequencies
5 MHz 47 MHz 54 MHz 90 MHz 200 MHz 500 MHz 698 MHz 800 MHz 862 MHz 950 MHz 1000 MHz 1220 MHz 1350 MHz 1750 MHz 2050 MHz 2150 MHz 2200 MHz 2300 MHz 2400 MHz 3000 MHz
Attenuation (typ.) dB / m
0.01 0.03 0.04 0.05 0.08 0.13 0.15 0.16 0.16 0.17 0.19 0.2 0.22 0.25 0.26 0.27 0.28 0.3 0.31 0.33
