Master Battery BATT-4035-U - Upower, Rechargeable battery, AGM lead-acid…

Name: Orbita Digital
Address: Dr. Francisco Grande Covian, 3, Oviedo, Asturias, 33011
Price range: €-€€€€

Upower - Rechargeable battery - AGM lead-acid technology - Voltage 4 V - Capacity 3.5 Ah - 65 x 90 x 34 / 420 g - For backup or direct use

€13.04

Tax included

Reference BATT-4035-U

Brand Master Battery

€13.04

Features

Brand	Upower
Nominal voltage	4 V
Nominal capacity	3.5 Ah (20HR)
Standby use	4.5 ~ 4.6 V
Cyclic use	4.8 ~ 5.0 V
Initial intensity	< 1.05 A
Maximum discharge intensity	52.5 A max.
Internal resistance	14 MΩ
Autodescarga	up to 6 months (25º)
Connection type	F1
Dimensions	65 (H) x 90 (W) x 34 (D) mm
Weight	420 g

Brand Master Battery

Weight: 2.5Kg
Dimensions: 58 x 100 mm (H x D) / 130g
370 x 410 x 80 mm
Temperature: -5ºC~+45ºC
IP protection: IP40
Primary power supply: Switching source 187-252V AC 50-60 Hz 65W max.
Backup power supply: 2 batteries 12VDC (up to 18 Ah). Ensures minimum 72 hours duration.
Number of zones: 16 zones, up to 30 detectors by area.
Siren outputs: 2 siren outputs 24VDC. Independent and monitored open collector outputs
Relay outputs: 8 Relay outputs: [VAR%] Alarm output, 1 Fault output and 1 configurable relay outputs. All support 30VDC 3A max.
End of line resistance: Areas fully monitored by end-of-line resistance (4.7K)
Auxiliary Output Voltage: 24VDC. Protected by resettable electronic fuse 1.85A
Protection Index: IP30
Material and colour: ABS, colour: White
Recommended cable: Fire cable with a minimum section of 1.0mm (18AWG).
Certification: EN54-5 y EN54-17
Series: AXIS
Consumption standby mode (Max.): 85μA
Consumption alarm (Max.): 20mA@24VDC
Voltage DC: Nominal Relay Switching current 24V (18~40V)
Available languages: Spanish, English, Portuguese, Italian, French, and German.
Alarm thresholds: Up to 2 selectable alarm thresholds
Operating temperature range: -10ºC ~ +55ºC
Humidity (non condensing): 95% RH
