Dahua NVR4116-8P-4KS2/L. Dahua 16 channel 4K / 8MP IP NVR. Smart H.265 + / Smart H.264 + / H.265 / H.264. Two-way audio. Playback of up to 16 channels. Recording resolution of 4K / 8MP, 5MP, 4MP, 3MP, 1080P, 720P, etc. 80/60 Mbps bandwidth. Simultaneous HDMI (4K) 1 VGA (1080P) outputs. Compatible with cameras with perimeter protection, SMD Plus and heat map. 1 SATA HDD capacity. 1 RJ45 Fast Ethernet. 2 USB 2.0. 48V DC / 53V DC. 8 PoE ports Nvr4116-8p-4ks2.

Specifications

    16 IP channels up to 4K / 8MP

    Video compression: Smart H.265 +, H.265, Smart H.264 +, H.264

    Simultaneous HDMI (4K) and VGA (1080P) video outputs

    Output division: 1, 4, 8, 9, 16

    1 RCA input / 1 RCA audio output

    Two-way audio via RCA input / output

    Audio compression: G.711a, G.711u, PCM, G726

    Recording resolution: 4K / 8MP, 5MP, 4MP, 3MP, 1080P, 720P, D1, CIF

    Bandwidth: 80 Mbps for access, 80 Mbps for storage and 60 Mbps for forwarding

    Decoding capacity: 2 channels at 8MP (25 ips), 4 channels at 4MP (25 ips), 8 channels at 1080P (25 ips)

    Manual, alarm, motion detection and timed recording modes

    Alarm by video sensor, by privacy mask, by video loss, IP camera

    Playback of up to 16 channels

    Internal capacity for 1 SATA HDD up to 10TB (sold separately)

    New user interface with a simpler user experience

    Supports perimeter protection, SMD Plus and heat map functions of compatible Dahua cameras

    Supports smart search by metadata

    Supports ANR (automatic network replenishment technology): In case of network failure, images are recorded on the IP camera's SD card, which are transferred to the NVR once the network is restored

    Software and hardware watchdog

    Watermark to preserve the integrity of the videos

    RJ45 Fast Ethernet network port (10 / 100Mbps)

    8 PoE ports (10 / 100Mbps) with an output power of 25.5W per port and a total of 72W

    Network protocols: HTTP, HTTPS, TCP / IP, IPv4, RTSP, UDP, NTP, DHCP, DNS, P2P

    ONVIF (Profile S), CGI and SDK compliant

    Remote access from web browser (IE9, Chrome, Firefox) and iPhone, iPad (iDMSS) and Android (gDMSS) devices

    Server Access local network and Internet

    Possibility of limiting user access to cameras in local and / or remote mode

    Can be remotely controlled by Joystick keyboard connected by TCP / IP

    Sending emails with attached photograph in alarm

    Send to FTP scheduled or in alarm

    Possibility of sending alarm, and being connected to video surveillance receiver software

    Possibility of fixed or dynamic IP through Dyndns service, NoIP, DDNS Evolution, etc.

    Communication ports: 2 USB 2.0 ports

    Power supply: 48V DC / 53V DC, 2A / 1.8A (≤10W, not counting discs)

    -10 ° C ~ + 55 ° C operating temperature

    10% ~ 90% relative humidity

    Dimensions: 270 (W) x 45.7 (H) x 206.3mm

    Weight: 700g
