Triax TLC 7235 Kit LTE700 mast amplifier and 24VDC power supply 20...35 dB

Kit consisting of TLC series mast amplifier and ALF 280 series power supply of 24Vdc and 180 mA. The TLC series mast amplifiers have 2 UHF inputs and 1 output and have an LTE filter cut off at 700 MHz (LTE/4G).

€76.87
Tax included
Reference triax-340185
Brand Triax
Quantity
Out-of-Stock

Free shipping

Kit consisting of TLC series mast amplifier and ALF 280 series power supply of 24Vdc and 180 mA. The TLC series mast amplifiers have 2 UHF inputs and 1 output and have an LTE filter cut off at 700 MHz (LTE / 4G).

Characteristics

  • 20 dB gain
  • Gain regulation 0 - 15 dB
  • 103 dBuV output level.
  • 700 MHz LTE protection
  • Plastic box made of materials resistant to atmospheric agents.
  • LED indicator of operation.
  • Low noise figure.
  • Current pass.
  • 12 to 24 Vdc power supply.
  • Simple and easy pole or wall mounting.

specs

Characteristics
Kind Amplifiers - Mast
Frequency range
Band UHF
Channels 21 ... 48
[Input 1] - frequency 470 ... 694 MHz
[Input 1] - channels 21 ... 48
[Input 2] - frequency 470 ... 694 MHz
[Input 2] - channels 21 ... 48
LTE protection @ 700Mhz
Gain
[Input 1] - gain 20 ... 35 dB
[Input 1] - noise figure 3.5 dB
[Input 2] - gain 20 ... 35 dB
[Input 2] - noise figure 3.5 dB
Return loss
Return losses > 10.0 dB
Electrical data
Impedance 75 Ω
Operational
LED indicator Green
DC working voltage 12 ... 24 VDC
Voltage consumption 65 mA
PSU / adapter INFO Including Euro Plug (CEE 7/17)
Connectors
Number of entries two
Number of outputs 1
Mechanical
Packaging Qty 1
Packing Height 0.176 m
Packaging Width 0.228 m
Packing Depth 0.058 m
Packaging Volume 0.002 m3
Net weight 0.680 kg
Tare weight 0.100 kg
Total weight 0.780 kg
