Triax MFA 657 Mast amplifier with protection LTE 700 and 800 MHz - 24 VDC

€50.31
Mast Preamps with LTE 700 and 800 MHz Protection - 24 VDC
TRIAX electronic products include a range of mast preamps with high-performance, easy-to-mount F-connectors. The MFA series includes multiband preamps with 1-2-3 inputs and 1-2 outputs, with channel cut-off to LTE 700 and 800 signals (Ch 49 ... 69 & Ch 60 ... 69)

Characteristics

  • 24 VDC power supply
  • LTE protection (LTE versions 700 and 800)
  • High output level
  • High resistance to external disturbances
  • High resistance to the corrosion
  • Optimized mechanism for easy installation
  • Neoprene cable clamp
  • Weather resistant housing
  • Tool for F connector included
  • RF protection and CE approval (EN50083)

Specifications

Characteristics
Kind Amplifiers - Mast
Output level max. (@ -60dB IMD) 108 dBµV
Frequency range
Band FM / VHF / UHF
[Input 1] - frequency 470 ... 694 MHz
[Input 1] - channels 21 ... 48
[Input 2] - frequency 87 ... 108 MHz
[Input 2] - channels FM
[Input 3] - frequency 174 ... 230 MHz
[Input 3] - channels DAB
LTE protection @ 700Mhz
Gain
[Input 1] - gain 20 ... 35 dB
[Input 1] - noise figure 2.5 (@ 174 ... 230MHz) 2.0 (@ 470 ... 694Mhz) dB
[Input 2] - gain 10 ... 22 dB
[Input 2] - noise figure 2.5 dB
[Input 3] - gain 10 ... 22 dB
[Entry 3] - noise figure 2.5 dB
Lost
Rejection @ 714 MHz (Ch. 51) 17.0 (@ gain = 30dB) dB
Return loss
Return losses 10 dB
Electrical data
Impedance 75 Ω
Operational
LED indicator Green
DC working voltage 24 VDC
Voltage consumption 42 mA
Connectors
Number of entries 3
Number of outputs 1
Mechanical
Colour RAL 7016 - Anthracite gray
Packaging Qty 1
Height 57 mm
Width 140 mm
Depth 113 mm
Packing Height 0.062 m
Packaging Width 0.140 m
Packing Depth 0.120 m
Packaging Volume 0.001 m3
Net weight 0.246 kg
Tare weight 0.040 kg
Total weight 0.286 kg
2021-10-18

Data sheet

Weight
350 g
Power
DC 12 V / 542 mA, PoE IEEE802.3af
Temp. operation
-40º C ~ +60º C
Degree of protection
Waterproof IP67, Anti-vandal IK10
Dimensions
81 mm (D) x 110 (Ø) mm
Alarm
No
Audio
No
Image sensor
1/2.8” Progressive CMOS
Minimum illumination
0.002 Lux (Color) @F1.6
Lens
2.8 mm (H: 106º)(V:56º)
Maximum resolution
2 Megapixel (1920x1080)
Infrared lighting
0 Lux / IR LEDs (30 m)
Image improvements
WDR, BLC, HLC, AWB, AGC, 3D-NR, ROI, Smart IR
Day / Night
Removable mechanical ICR filter
Remote access
WEB, CMS (DSS/PSS), Smartphone and NVR interface
Main Stream rate
1920x1080 (1~25/30 FPS)
Extra Stream rate
704x576 (1 ~ 25 FPS), 704x480 (1 ~ 30 FPS)
Compression
H.265+/H.265/H.264+/H.264
Network interface
Ethernet 10/100 BaseT
Video analysis
Line crossing | Area intrusion
Interoperability
ONVIF
Lens Adjustment
3 Axis
External storage
256 GB microSD card slot
