Triax MFA 2642 Mast amplifier with protection LTE 700 and 800 MHz - 24 VDC

Mast amplifier MFA 2642 LTE 700 (LTE/5G). Low noise figure. It has 2 inputs: VHF (DAB) and UHF and a single high-level output 108 dBμV. Plastic box made of materials resistant to atmospheric agents. Complies with RED regulations. LED indicator of operation. Adjustable gain. 24 Vdc power supply. Consumption 45 mA. Simple and easy pole or wall mounting.

€110.93
Tax included
Reference triax-340629
Brand Triax
Quantity
Out-of-Stock

Free shipping
Mast amplifier MFA 2642 LTE 700 (LTE / 5G).

Characteristics

  • 24 VDC power supply
  • LTE protection (LTE versions 700 and 800)
  • High output level
  • High resistance to external disturbances
  • High resistance to the corrosion
  • Optimized mechanism for easy installation
  • Neoprene cable clamp
  • Weather resistant housing
  • Tool for F connector included
  • RF protection and CE approval (EN50083)

Specifications

  • 1 FM + VHF input (87 ... 108/174 ... 230 MHz.) FM + VHF gain from 10 to 21 dB
  • 1 UHF input (470..694 MHz) UHF gain from 30 to 42 dB.
  • 1 exit. Output level 108 dBμV. 24 VDC power supply
  • Low noise figure.
  • It has 2 inputs: VHF (DAB) and UHF and a single high-level output 108 dBμV.
  • Plastic box made of materials resistant to atmospheric agents.
  • Complies with RED regulations.
  • LED indicator of operation.
  • Adjustable gain.
  • 24 Vdc power supply.
  • Simple and easy pole or wall mounting.
  • Input 1 Band BI + FM + BIII 47 - 230MHz.
  • Channel 5 - 12 / Input 2 UHF Band 470 - 694MHz Channel 21 - 48.
  • Gain BI + FM + BIII dB 11 - 26 / UHF dB 21 - 36
  • Noise figure BI + FM + BIII 2.8dB / VHF UHF 1.8dB.
  • F-female connectors
  • Weight 0.205kg
2021-10-14

Data sheet

Dimensions
1U, 48 (H) x 260 (W) x 225 (D) mm / 0.8 Kg (without HDD)
Power supply
DC 12 V / 1.5 A / PoE IEEE802.3af
Communication
2x USB 2.0 (Mouse and backup) /1 RJ45 10/100M (Ethernet)
Inputs for IP cameras
4 channels
Bidirectional audio
1 entrada RCA, 1 salida RCA
Video compression format
H.265+/H.265/H.264+/H.264/MJPEG
Total bandwidth
80 Mbps
Simultaneous multifunction
Pentaplex: Live, Recording, Playback, Backup and Remote Access
Alarms
No
Recording method
Manual, programmed, motion detection
Internal memory
1 SATA HDD 3.5\" of up to 8 TB (not included)
Remote access
Web browser (ActiveX), mobile phone application or PSS software
Video outputs
1 HDMI 4K, 1 VGA
Recording resolution
12Mp, 8Mp (en 1 canal), 6Mp, 5Mp, 4Mp, 3Mp, 1080P (en 4 canales), 720P, D1...
Backup
USB (Memory, HDD, CD-RW, DVR-RW) / Network / SATA internal interface
Video analysis
IVS: Cruce de línea | Intrusión en área | Detección de rostro
Detección de movimiento inteligente
Hasta 2 canales capaces de clasificar objetivos entre humanos y vehículos
Facial recognition
1 live analogue face comparison channel
