Triax TOS 08 F 1 input, 8 metal outputs, optical splitter distributor, FC/PC connectors, attenuation in distribution 10.1 dB
TOS 08F, 8-way PLC Splitter FC/PC. The balanced coupler is implemented in a valid metal housing. Pre-assembled with FC/PC connectors. PLC (Planar Lightwave Circuit) couplers with a wide window of wave lengths. Low and flat insertion loss.
€122.98
Tax included
Reference
triax-307737
Brand
Triax
TOS 08F, 8-way PLC Splitter FC/PC
The balanced coupler is implemented in a valid metal housing
- pre-assembled with FC/PC connectors
- PLC (Planar Lightwave Circuit) couplers with a wide window of wave lengths
- Low and flat insertion loss
Specifications
| CHARACTERISTICS | |
|---|---|
| Type | OPTO Coupler balanced |
| Coupling Ratio (OPTO) | 8x 12.5 % |
| Wavelength | 1260...1650 nm |
| LOSS | |
| Insertion loss (typ.) | 10.2 dB |
| CONNECTORS | |
| Connector Type | Optical - FC/PC |
| Number of inputs | 1 |
| Number of outputs | 8 |
| MECHANICAL | |
| Dimensions product (H x D x W) | 150x20x114 mm |
| Packing QTY | 1 |
| Packaging Height | 0,045 m |
| Packaging Width | 0,153 m |
| Packaging Depth | 0,213 m |
| Packaging Volume | 0,001 m3 |
| Net Weight | 0,286 kg |
| Tara Weight | 0,064 kg |
| Total Weight | 0,350 kg |
2021-10-18
Data sheet
- Dimensions
- 1U, 48 (H) x 260 (W) x 225 (D) mm / 0.8 Kg (without HDD)
- Power supply
- DC 12 V / 1.5 A
- Communication
- 2x USB 2.0 (Mouse and backup) /1 RJ45 10/100M (Ethernet)
- Inputs for IP cameras
- 8 canales
- Bidirectional audio
- 1 entrada RCA, 1 salida RCA
- Video compression format
- H.265+/H.265/H.264+/H.264/MJPEG
- Total bandwidth
- 80 Mbps
- Simultaneous multifunction
- Pentaplex: Live, Recording, Playback, Backup and Remote Access
- Alarms
- No
- Recording method
- Manual, programmed, motion detection
- Internal memory
- 1 SATA HDD 3.5\" of up to 8 TB (not included)
- Remote access
- Web browser (ActiveX), mobile phone application or PSS software
- Video outputs
- 1 HDMI 4K, 1 VGA
- Recording resolution
- 12Mp, 8Mp (en 1 canal), 6Mp, 5Mp, 4Mp, 3Mp, 1080P (en 4 canales), 720P, D1...
- Backup
- USB (Memory, HDD, CD-RW, DVR-RW) / Network / SATA internal interface
- Video analysis
- IVS: Cruce de línea | Intrusión en área | Detección de rostro
- Detección de movimiento inteligente
- Hasta 2 canales capaces de clasificar objetivos entre humanos y vehículos
- Facial recognition
- 1 live analogue face comparison channel
TOS 08F, 8-way PLC Splitter FC/PC. The balanced coupler is implemented in a valid metal housing. Pre-assembled with FC/PC connectors. PLC (Planar Lightwave Circuit) couplers with a wide window of wave lengths. Low and flat insertion loss.
