Data sheet

Weight

96 g
230 g

Power

1 battery CR2032 of 3 V
AC 110~250 V, 50/60 Hz
DC 12 V / 5.3W.

Resolution

8 Mpx (3840x2160) at 15 FPS

Technology

Volumetric PIR with photo camera

Detection range

12 m / H: 88.5º / V: 80º / Installation 2.4 m

Frequency

868 MHz
868 MHz Jeweller
868 MHz Jeweller and Wings (sending images)

Pet immunity

≤ 20 kg, ≤ 50 cm

Masking

No

Sensitivity

Adjustable. 3 levels (low, medium and high)

LEDs indication

Alarm, tamper, signal

Battery

1 battery CR123A 3.0 V (approximate life time 5 years)
1 battery CR123A 3.0 V (approximate life time 7 years)
2 CR123A3.0 v-batteries (life up to 4 years)
2 batteries CR123A 3.0 V (approximate life time 5 years)
4 AAA batteries 1.5 V (approximate life time 2 years)

Temp. operation

+5º C ~ 40º C
-10º C ~ +50º C
-10º C ~ 50º C
-20º C ~ 50º C
0º C ~ 40º C

Degree of protection

Weatherproof IP67

Units

2

Security grade

Grade 2

Transmission distance

≤ 1000 m in open space
≤ 1700 m in open space
≤ 2000 m in open space

LED indicators

Alarm warning and sound signal when armed/disarmed

Housing material

ABS plastic

Volume

81~97 dB at 1 meter

Alarm duration

Configurable between 3 seconds and 3 minutes

Internal security

Tamper-resistant back
Tamper-resistant opening

Protection

IP50

Dimensions

65 (H) x 37 (W) x 10 (D) mm
75 (H) x 75 (W) x 27 (D)mm
90 mm (D) x 20 (Ø) mm
146 (D) x 72 (W) x 83 (H) mm
150 (H) x 102.5 (W) x 13.2 (D) mm
163 (H) x 163 (W) x 36 (D) mm

PIR lens

24 zones and 6 planes

Backup battery

Duration up to 15 hours

Internal siren

No

Range

HDCVI 8 Mpx IoT Active Deterrence

RF frequency

868 MHz. Protocol via Jeweller wireless technology

Communication

Ethernet / Wi-Fi / Dual SIM 4G (LTE)

Maximum devices

200

Number or users

Up to 200

Functions

Armed, disarmed, partially armed and emergency

Compatibility

AJ-HUB2-W/B
Compatible with Ajax Hubs with firmware 2.0 or higher
Not compatible with ocBridge and uartBridge

Video output

1 x BNC HDCVI

Image sensor

1/2\" 8 Megapixel CMOS

DSP

Integrated

Minimum illumination

0 Lux / IR LEDs (20 m)

Basic functions

OSD menu, Day/Night with IR-CUT (ICR)

Configurable OSD functions

WDR, Smart IR, AWB, AGC, BLC, HLC, 2DNR

Lens

2.8 mm (H: 107º)

Infrared lighting

IR for night mode

Image resolution

Up to VGA (640 x 480)

PIR detection field

10 m / H: 110º / Installation 2.2~2.5 m

Video integration

Up to 100 IP cameras or video recorder channels

Connection with CRA

Contact ID / SIA

Dimensions (without bracket)

135 (H) x 70 (W) x 60 (D) mm

Number of images

Up to 5 images per detection

Sending images

Sending and receiving images in less than a minute

LED Alarm

Red LED
