Double FO Singlemode LSFH Dca Patch Cord Preconnected SC/APC 55m Televes
Single-mode (SM) optical-fibre patch cord Pre-terminated with SC/APC connectors for the connection of the elements of an optical network. Furthermore, since they are duplex, they are suitable for use in point-to-point networks that use the same window for both upstream and downstream traffic. The sheath being LSFH, it is recommended for indoor use.
€102.25
€157.30
Save 35%
Tax included
Reference
televes-232657
Brand
Televes
Double FO Singlemode LSFH Dca Patch Cord Preconnected SC/APC 55m Televes
€102.25
€157.30
Save 35%
Single-mode (SM) optical-fibre patch cord Pre-terminated with SC/APC connectors for the connection of the elements of an optical network. Furthermore, since they are duplex, they are suitable for use in point-to-point networks that use the same window for both upstream and downstream traffic. The sheath being LSFH, it is recommended for indoor use.
Highlights
- Low attenuation levels and high reliability
- Connectors mechanically outphased on one end to facilitate wiring
- Equipped with locks and removable fixing devices: the fibres may be kept together or separate
- Includes identifiers for each of the fibres
- Dca-s2,d2,a1 Euroclass
Main features
- ITU-T G.657A2 fibre type
- Duplex patch cord: two fibre cables
- LSFH sheath, orange colour
- SC/APC connectors
- Length 55m
Specifications
| Technical specifications | ||
| Euroclass | Type | Dca-s2,d2,a1 |
| Fiber | Type | Single Mode |
| Opctics connectors | Type | SC/APC |
| Cover material | Type | LSFH |
| Attenuation | dB | ≤ 0,8 |
| Insertion losses | dB | < 0,5 |
| Return losses (in each patch cord ) | dB | >60 |
| Minimum radius of curvature | mm | 30 |
| Outside diameter of the fiber | mm | 3 |
