DTKom broadband multiband amplifier 5 inputs: FM-BIII-21..32-36..48-UHF LTE700 Televes

High-power multiband amplifier with multiple controls on the front end, which design uses components that minimize the total noise figure. Equipped with 5 inputs (FM-BIII-21...32-36...48-UHF). The UHF band is divided in 2 of the inputs, which is useful in two-repeater reception installations since it allows an appropriate filtering of the channels for each of them. LTE700

€116.40 €179.08 Save 35%

Tax included

Reference televes-534121

Brand Televes

DTKom broadband multiband amplifier 5 inputs: FM-BIII-21..32-36..48-UHF LTE700 Televes

€116.40 €179.08 Save 35%

Description
Product Details

Equipped with LTE700 filtering.

RED compliant

Highlights

Separate amplification minimizes intermodulation between bands and provides high output levels
Designed using Push-Pull technology, which guarantees levels in the 123 dBμV range for terrestrial signals.
Includes a high-performance low-power consumption switch-mode power supply
High-screening Zamak chassis The design facilitates appropriate cooling

Features

Switch for pre-amplifier or BOSS system powering
Switched configurable gain (high/low), and high output level
Intuitive front cover, including adjustments and block diagram
Output signal LED indicator

Specifications

Bands			UHF	BV	BIV	BIII	FM
Frequency margin		MHz	470 ... 694	590... 694 (Ch36...48)	470 ... 566 (Ch21...32)	174 ... 370	88 ... 108
Gain	0	dB	42	41⁽¹⁾	41⁽²⁾	42	25
	10		32	31⁽¹⁾	31⁽²⁾	32	25
Gain margin			(Manual) 0 ... 20	(Manual) 0 ... 20	(Manual) 0 ... 20	(Manual) 0 ... 20	(Manual) 0 ... 20
Max. output level	IMD3 (2 tones,-35 dB)	dBμV (dBmV)	125 (65)
	DIN 45004B		123 (63)
	IMD3 (2 tones,-60 dB)		120 (60)
	IMD2 (2 tones,-60 dB)		-	-	-	122 (62)	-
Noise figure		dB	10	10	10	5	6
Test			-20
Powering inputs		V=	12
Max. curent inputs		mA	50
Mains voltage /frequency		V~ / Hz	120 ... 230 / 50-60
Total AC consumption	OFF	W / mA	5,8 / 120
	ON	W / mA	9,6 / 180
Protection level		IP	20
Operating temperature range		ºC (ºF)	-5 ... +45 (23 ... 113)

Data sheet

Weight: 1.82 Kg
2 x 200 g
Power: 2 x DC 5 V / 2A
18~30VAC, 9~15VDC, PoE IEEE802.3at
Resolution: 480p/576p/720p/1080p
Temp. operation: 10º C ~ +35º C
Degree of protection: Weatherproof IP66
Dimensions: 2 x 23.2 (H) x 130 (W) x 84 (D) mm
376.1 mm (Fo) x 118.1 (An) x 119.1 (Al) mm
Alarm: 2 / 2 In / Relay
Audio: 1 Input / 1 line level output 600 ohm
Lens: 15 mm (Therm) / 6 mm (Opt)
Viewing angle: 24.5°×18.5° (Term) / 51.7°×28° (Opt)
Internal memory: Micro SD card up to 256GB
Remote access: WEB, CMS (DSS/PSS), Smartphone and NVR interface
Main Stream rate: 384x288(50fps) Thermal / 2560x1520 (25fps) Optical
Extra Stream rate: 384x288 (50fps) Thermal / 704x576 (25fps) Optical
Compression: H.265+ / H.265 / H.264+ / H.264 / MJPEG
Network interface: Ethernet 10/100 BaseT
Maximum distance: 120 m
Extension cable: UTP Cat 6 (RJ45)
Signal Type: HDMI (including audio and IR signal)
Interoperability: ONVIF
Installation height: 1.7 - 2.5m
Intelligent functions: Body temperature measurement
Thermal sensor: 384x288 Vanadium Oxide
Optical sensor: 1/2.7” Progressive Scan CMOS 4 Megapixel
VCA ranges: 3 temperature measurement rules, up to 21 rules in total (10 points, 10 areas and 1 line)
Thermal sensitivity: ≤ 35mK (0.05 º C)
Thermal measurement range: 30 ~ 45ºC / Alta precisión ± 0.5ºC( ± 0.3ºC incluyendo Blackbody)
Spectral range: 8~14μm
Pitch detector: 17μm
Minimum illumination (for optical part): Colour: 0.0089 Lux @ (F1.6, AGC ON), IR up to 50 m distance
Features in Measurement: Up to 30 face detections in the same scene / Between 2.5 ~ 9 m of distance in the detection
Standard: HDbitT v1.3f
