  • Engenius ENSTATION5-AC - ENGENIUS wireless link, Frequencies 5.15GHz, 5.85 GHz,…

Engenius ENSTATION5-AC - ENGENIUS wireless link, Frequencies 5.15GHz, 5.85 GHz,…

ENGENIUS wireless link - Frequencies 5.15GHz - 5.85 GHz - 802.11a/n/ac Support | Wave 2.0 Technology - IP55, suitable for exterior - Directional antenna 19 dB - Transmission speed up to 866 Mbps
€143.00 €220.00 Save 35%
Tax included
Reference ENSTATION5-AC
Brand Engenius
Quantity
Available in 24/48h

Free shipping
Engenius ENSTATION5-AC - ENGENIUS wireless link, Frequencies 5.15GHz, 5.85 GHz,…

Engenius ENSTATION5-AC - ENGENIUS wireless link, Frequencies 5.15GHz, 5.85 GHz,…

€143.00 €220.00 Save 35%
  • EnGenius
  • High-capacity wireless device 802.11ac/a/n at 5 GHZ
  • High power 400 mW for long distances
  • IP65, suitable for exterior
  • Compatible with the standard 802.11 ac/a/n, allows connections at 866 Mbps
  • Working frequencies 5.18 GHZ
  • 5.82 GHZ
  • Integrated antenna 19 dB (30º Az and 30º E)
  • Ideal for point-to-point connections or as "client" antenna
  • Permits wireless transmission of IP devices (camera or DVR) to the checkpoints

Features

  • ENGENIUS wireless link
  • Frequencies 5.15GHz - 5.85 GHz
  • 802.11a/n/ac Support | Wave 2.0 Technology
  • IP55, suitable for exterior
  • Directional antenna 19 dB
  • Transmission speed up to 866 Mbps

Specs

Wireless Standard802.11 ac/a/n
Frequencies5.15GHz– 5.85 GHz
Maximum power transmission10 dBm
Transmission speed866 Mbps
Maximum sensitivity91 dBm at MCS0/MCS9
Integrated antennaDirectional 19dB
Operating modesAccesspoint, Client bridge, WDS
SecurityWEP / WPA2 / Hidden SSID / Client isolation / SSH Tunnel / MAC filtering
NetworkingDHCP, VPN, PPTP, PPoE, spanning tree, reserve bandwidth
ManagementConfiguration via web interface
PowerPoE (own design)
Consumption7W
Operating temperature-20ºC–60 º C
Dimensions190 (Al) x 98 (Fo) mm

Package content

  • Wireless link
  • Bracket
  • PoE injector
  • Installation material
  • Power adapter AC/DC 24 V
  • User instructions

Data sheet

Power
PoE (own design)
Dimensions
190 (Al) x 98 (Fo) mm
Operating temperature
-20ºC–60 º C
Power supply
PoE (own design)
Wireless Standard
802.11 ac/a/n
Frequencies
5.15GHz– 5.85 GHz
Maximum power transmission
10 dBm
Maximum sensitivity
91 dBm at MCS0/MCS9
Operating modes
Accesspoint, Client bridge, WDS
Security
WEP / WPA2 / Hidden SSID / Client isolation / SSH Tunnel / MAC filtering
Management
Configuration via web interface
Transmission speed
866 Mbps
Integrated antenna
Directional 14dB
Directional 19dB
Networking
DHCP, VPN, PPTP, PPoE, spanning tree, reserve bandwidth
